Altronix Isolated Series Installation Manual page 6

Enclosure Dimensions
(H x W x D approximate) for
• ALTV248ULMi • ALTV248ULCBMi
8.5" x 7.5" x 3.5" (215.9mm x 190.5mm x 88.9mm)
1.25"
(31.75mm)
2"
(50.8mm)
2"
(50.8mm)
8.125"
(206.375mm)
- 6 -
0.6"
(15.24mm)
1.125"
(28.575mm)
1"
(25.4mm)
0.6"
(15.24mm)
1"
(25.4mm)
Available from A1 Security Cameras
www.a1securitycameras.com email: sales@a1securitycameras.com
7.25"
(184.15mm)
3.625"
(184.15mm)
(31.75mm)
6.05"
(153.67mm)
(28.575mm)
(25.4mm)
6.05"
(153.67mm)
(15.24mm)
(25.4mm)
5.25" 1"
(133.35mm) (25.4mm)
1.25"
3.5"
(88.9mm)
0.6"
(15.24mm)
1.125"
1"
0.6"
1.25"
(31.75mm)
3.5"
(88.9mm)
1"
UL Listed Isolated Series
