StarBrite
StarBrite Controller
PR-8710
PR-8710C
This product manual contains important information about the safe installation and use of this
product. Please read and follow these instructions carefully and keep this manual in a safe place
for future reference.
PR LIGHTING LTD.
http://www.pr-lighting.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the StarBrite and is the answer not in the manual?

Questions and answers

Related Manuals for PR Lighting StarBrite

Summary of Contents for PR Lighting StarBrite

  • Page 1 StarBrite StarBrite Controller PR-8710 PR-8710C This product manual contains important information about the safe installation and use of this product. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PR LIGHTING LTD.
  • Page 2 INDEX SAFE USAGE OF THE PRODUCT INSTALLING THE PRODUCT POWER SUPPLY – MAINS CONTROL CONNECTIONS DMX TERMINATOR SETUP OPTIONS-PRODUCT CONFIGURATION OPERATION MENU TO SET THE DMX START ADDRESS DMX PROTOCOL LED INDICATION MAINTENANCE TROUBLESHOOTING TECHNICAL DATA ELECTRICAL DIAGRAM COMPONENT ORDER CODES Please note that as part of our ongoing commitment to continuous product development, specifications are subject to change without notice.

  • Page 3: Safe Usage Of The Product

    If the LED StarBrite Controller is put on a table, make sure the table is stable and fix the controller on the center of the table. Do not put the controller on the fringe of the table in case of falling.

  • Page 4: Power Supply-Mains

    Generally, LED StarBrite Controller can be put on a flat surface , such as a table, or a floor, but if you want to mount it on a higher place, fix both the top and bottom fringes of the controller by four screws into the four screw eyelets, and use a proved safety cord through the hole prearranged in the middle of the top fringe as a secondary safety fixing at the same time.
  • Page 5 The product accepts digital control signals in protocol DMX512 (1990). First of all, connect a LED StarBrite Controller and a LED StarBrite, and it can run in the stand-alone mode with 12 preset programs, according to the different applications, the Master/Slave mode and the DMX control mode can be selected.

  • Page 6: Dmx Terminator

    DMX TERMINATOR In the DMX control mode, for the last LED StarBrite Controller in the chain, the DMX OUT port has to be connected with a DMX terminator. This prevents electrical noise from disturbing and corrupting the DMX control signals.

  • Page 7: Operation Menu

    OPERATION MENU Menu Description PROGRAM 1 Speed[XX] Save PROGRAM 2 Speed[XX] Save PROGRAM 3 Speed[XX] Save PROGRAM 4 Speed[XX] Save PROGRAM 5 Speed[XX] Save PROGRAM 6 Speed[XX] Save range of XX :1~16 PROGRAM 7 Speed[XX] Save PROGRAM 8 Speed[XX] Save PROGRAM 9 Speed[XX] Save...

  • Page 8: To Set The Dmx Start Address

    TO SET THE DMX START ADDRESS When a console is used to control several LED StarBrite Controllers, so that to control more LED StarBrites, each LED StarBrite Controller must be given a DMX start address so that the correct LED StarBrite Controller responds to the correct control signals.

  • Page 9: Dmx Protocol

    DMX PROTOCOL CHANNEL FUNCTION DESCRIPTION 000-240 Dimming, from dark to light 241-255 Strobe, from slow to fast 000-240 Dimming, from dark to light Green 241-255 Strobe, from slow to fast 000-240 Dimming, from dark to light Blue 241-255 Strobe, from slow to fast 000-240 Dimming, from dark to light 241-255...
  • Page 10 241-255 Strobe, from slow to fast 000-240 Dimming, from dark to light Blue 241-255 Strobe, from slow to fast 000-240 Dimming, from dark to light 241-255 Strobe, from slow to fast 000-240 Dimming, from dark to light Green 241-255 Strobe, from slow to fast 000-240 Dimming, from dark to light Blue...

  • Page 11: Led Indication

    MAINTENANCE When a LED StarBrite is used or stored for a long time, dust and dirt will accumulate on its surface. To maintain an optimum light output, prolong the product’s life and ensure its reliability, it is very important to carry out the maintenance work.

  • Page 12: Technical Data

    LED StarBrite : 10V~15V DC POWER CONSUMPTION: LED StarBrite Controller : Input: 200W, Output:150W(Max)（It can drive four pcs of LED StarBrite） LED StarBrite : Less than 30W BRIGHTNESS OF LED STARBRITE: More than 150cd when all the LEDs emit white light WORK ENVIRONMENT TEMPERATURE: 0℃~40℃...

  • Page 14: Component Order Codes

    COMPONENT ORDER CODES NAME PART NO. QUANTITY REMARK POWER SOCKET 210020012 PST-101 10A/250V POWER SWITCH 190010009 Red ,with indicator Input：AC85~132V/AC170~264V POWER SUPPLY 192010133 Output：DC15V,15A 5-PIN SIGNAL 212020059 YS1465-J5F2C CONNECTION SOCKET CONTROL PCB OF 230060052 LED STARTBRITE CONTROLLER CONTROL PCB OF 230060054 LED STARTBRITE LED MOUNTING PCB OF LED...
  • Page 15 15/16...
  • Page 16 PR LIGHTING LTD. PR New Hi-tech Science Park, 1582 Xingye Avenue Nancun Panyu, Guangzhou, 511442 China TEL: +86-20-3995 2888 FAX: +86-20-3995 2330 P/N: 320050002 Preliminary Revision: 20090220 16/16...
