PR Lighting AQUA LED 730 FRAMING User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AQUA LED 730 FRAMING
PR-8179
This product manual contains important information about the safe installation and use of this projector.
Please read and follow these instructions carefully and keep this manual in a safe place for future reference.
PR LIGHTING LTD.
http://www.pr-lighting.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AQUA LED 730 FRAMING and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PR Lighting AQUA LED 730 FRAMING

Summary of Contents for PR Lighting AQUA LED 730 FRAMING

  • Page 1 AQUA LED 730 FRAMING PR-8179 This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PR LIGHTING LTD.

  • Page 2: Table Of Contents

    Any damage caused by improper use will not be assumed by the manufacturer and / or dealer. Any future technical changes are not subject to further notice. Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from...

  • Page 3: Safety And Warnings

    the delivery date but the light source is not within the warranty. 1. SAFETY AND WARNINGS NOTE Before a projector’s installation, power-on, operation and maintenance, please carefully read the safety information hereinafter! The following safety signs are used in the user manual. User Electrical Protective...

  • Page 4: Instructions

    Do not switch on and off the projector constantly in very short intervals, otherwise the light source’s and other ● electrical parts’ life will be shortened . The projector is of class IP65, and not used in the environment higher than it. ●...

  • Page 5: Lubrication

    LUBRICATION ● To ensure smooth movement of gobos and focus lens, it’s advised rotators’ bearings and 2 sliding bars for focus lens be lubricated every 2 months. High quality and high temperature lubricant/grease is advised.. TROUBLESHOOTING ● PROBLEM ACTION  Check if the fuse is burned ...

  • Page 6: Power Connections

    警告 Warning 请把保险绳穿过两个保 please run the safety cords through 2 safety 吊钩 Clamp 险绳扣板上以确保安全 cord holes to ensure safety 保险绳 Safety cord 提手 Handle 保险绳扣板 Safety cord holes Take 2 clamps and 1 safety cords out from the package and mount 2 clamps on the underside of fixture with 4 retainers attached to each clamp.

  • Page 7: Dmx Terminator

    mustn’t be connected in any way other than mentioned in the above figure. The projector accepts digital control signals in protocol DMX512 (1990). Connect the controller’s DMX output to the first fixture’s DMX input, and connect the first fixture’s DMX output to the second fixture’s DMX input and connect the rest fixtures in the same way.

  • Page 8: Setup And Configuration

    Lock tilt and unfasten 4 screws of the small cover of the head. Open the cover and you’ll see the structure as above. 1→2. It’s installation Replacement of the color filter. Pull out the color filter directly by hand as the figure hereinafter in the sequence is in reverse sequence as the removal（2→1）.

  • Page 9: Dmx Wireless Control

    has 38 channels, so set the No. 1 projector’s address 001, No. 2 projector’s address 039, No. 3 projector’s address 077, No. 4 projector’s address115, and so on. Launch the projector. Press button ENTER more than 3seconds to unlock panel. Press button ENTER to display DMX address;...

  • Page 10: Operation Menu

    主机 从机 从机 MASTER SLAVE SLAVE 回路插 DMX CONTROLER DMX TERMINATOR 输入 输出 输入 输出 输入 OUTPUT INPUT OUTPUT INPUT INPUT INPUT 6. OPERATION MENU 1st LEVEL 2nd LEVEL 3rd LEVEL 4th LEVEL 5th LEVEL 1-474 DMX Address Default IP Address 2.X.X.X /10.X.X.X IP Address Custom IP Address...
  • Page 11 Pan Tilt Swap OFF/ ON XY Feedback OFF/ ON Pan/Tilt mode Speed/Time Iris Invert OFF/ ON Zoom Invert OFF/ ON Invert Settings CYM Invert OFF/ ON CTO Invert OFF/ ON Defaults Restore Defaults? Confirm/ Cancel View DMX Values Lamp Hours Reset Lamp Hours Total Hours Display Board XX℃/F...

  • Page 12: Dmx Protocol

    Strobe XXX Dimmer XXX Edit User Memory 1 … Scene XX （1~200 Scenes） Delay Time XXX Edit User Memory 2 Delay Unit Edit User Memory User Link To Step XXX Memories Strobe XXX Edit Static Scene Dimmer XXX … Reset User Memory 1 Reset User Memory? Input Password 123 Reset User Memory 2...
  • Page 13 Colour Macro 19 Colour Macro 20 Colour Macro 21 Colour Macro 22 Colour Macro 23 Colour Macro 24 Colour Macro 25 Colour Macro 26 Colour Macro 27 Colour Macro 28 Colour Macro 29 Colour Macro 30 Colour Macro 31 Colour Macro 32 Colour Macro 33 Colour Macro 34 Colour Macro 35...
  • Page 14 Colour Macro 62 Colour Macro 63 Colour Macro 64 Colour Macro 65 Colour Macro 66 Colour Macro 67 Colour Macro 68 Colour Macro 69 Colour Macro 70 Colour Macro 71 Colour Macro 72 Colour Macro 73 Colour Macro 74 Colour Macro 75 Colour Macro 76 Colour Macro 77 Colour Macro 78...
  • Page 15 Yellow in 16 Bit precision Magenta Magenta (Linear 0-100%) Magenta Fine Magenta in 16 Bit precision Linear adjust from high to low CTO Fine CTO in 16 Bit precision Colour Wheel Continual positioning index 0-360° positioning White White/colour 1(Purple) Colour 1(Purple) Colour 1(Purple)/colour 2(Red) Colour 2(Red) Colour 2(Red)/colour 3(Pink)
  • Page 16 Iris Macro5(Macro2 at random) with speed from slow to fast Iris Macro6(Macro3 at random) with speed from slow to fast Open Fixed gobo wheel White Gobo1 Gobo2 Gobo3 Gobo4 Gobo5 Gobo6 Gobo7 Clockwise rotation from slow to fast Anti-clockwise rotation from slow to fast Gobo1 shake from slow to fast Gobo2 shake from slow to fast Gobo3 shake from slow to fast...
  • Page 17 Rotating gobo wheel fine rotation Framing blade 1 left Framing blade 1 left linearly closing from big to small Framing blade 1 left in 16 bit Framing blade 1 left fine adjustment Framing blade 1 right Framing blade 1 right linearly closing from big to small Framing blade 1 right in 16 bit Framing blade 1 right fine adjustment Framing blade 2 left...
  • Page 18 Prism Prism rotation Prism index Prism stops Rotation speed from slow to fast Stop rotating Reverse rotation speed from slow to fast Effect Wheel No effect wheel Effect wheel in Effect Wheel Rotation Forwards rotation from slow to fast Reverse rotation from slow to fast Frost Light Frost from 0% to 100% Focus...

  • Page 19: Logos On The Screen

    Reserved Pan/Tilt reset Colour system reset Gobo wheels reset Reserved Zoom/focus/frost/prism reset Others(Iris/ effect wheel/Framing module) reset Total reset Reserved Reserved Note: 1） Fan error can automatically turn the LED lamp off. 2）Note: "Speed Mode" means Pan and Tilt will move from Point A to Point B at their respective maximum speeds."Time Mode" means both Pan and Tilt will arrive at designated point at the same time.

  • Page 20: Technical Data

    Timeout Check if wiring, positioning parts and motors are normal Rot. Gobo1Rotation Timeout Check if wiring, positioning parts and motors are normal Dimmer Timeout Check if wiring, positioning parts and motors are normal Prism Timeout Check if wiring, positioning parts and motors are normal Prism Rotation Timeout Check if wiring, positioning parts and motors are normal...
  • Page 21 Blue Purpl Linear CTO system(0-100%) Green Pink Orange GOBOS 1 rotating gobo wheel: 6 exchangeable+ white, glass or metal gobos Bi-directional rotation, indexing, shake with varied speeds, bi-directional scrolling with varied speeds Rotating gob wheel: Rotating gobo external size: 37.5mm; fixed gobo size 36.3mm Image size 26mm 1 fixed gobo wheel 7 exchangeable gobos+ white...
  • Page 22 EFFECT WHEEL 1 exchangeable graphic effect wheel, bi-directional rotation with varied speeds FOCUS 0-100% linearly adjustable by DMX DIMMER Linear dimmer 0-100% IRIS Linear iris 5-100% with macros STROBE Double shutter blades, 0.3~20 F.P.S HEAD MOVEMENT Pan 540º , Tilt 270º with auto position correction BEAM ANGLE Linear zoom 7°...

  • Page 23: Circuit Diagram And Pcb Connections

    WORK TEMPERATURE -20℃ ~ 45℃ WEIGHT 57Kg SIZES: See figures below: LIGHT OUTPUT: 60°Lux 7°Lux DISTANCE (m) 7°DIAMETER(m) 0 60°DIAMETER(m) 11. CIRCUIT DIAGRAM AND PCB CONNECTIONS CIRCUIT DIAGRAM ●...

  • Page 24: Pcb Connections

    PCB CONNECTIONS ● Name...
  • Page 25 Reserved Display board Reserved DMX signal input Reserved 24V Input Battery Fan for Power supply Fan for base Key board DMX signal input LCD Display Ethernet Signal Input Driver board 1 Name Effect wheel in/put motor Effect wheel rotation motor Reserved Fan for gobo wheels 24V input...
  • Page 26 Fan board DMX signal input DMX signal output PWM dimmer signal 1 PWM2 dimmer singal2 Reserved Reserved Reserved Head fan output Reserved LED temperature sensor Reserved 24Vinput Reserved Reserved Driver board3 Name Frost motor Prism motor Prism rotation motor Framing module rotation motor Fixed gobo wheel motor Iris motor Reserved...
  • Page 27 Driver board2 Name Cyan motor of CMY Yellow motor of CMY Magenta motor of CMY Reserved Reserved 24V input Reserved Reserved Magnet sensor for magenta filter Magnet sensor for yellow filter Magnet sensor for Cyan filter Magnet sensor for CTO Magnet sensor for color wheel DMX signal input Motor for color wheel...

  • Page 28: Component Order Codes

    LED Driver board ● Name PWMInput LED Driver output LED Driver output 48V Input + 48V Input - 12. COMPONENT ORDER CODES NAME PART NO. QUANTITY REMARK POWER SUPPLY A350e-24P 192010206 POWER SUPPLY 1000G-4824 192010220 LED ENGINE 150020314 FAN FOR LED ENGINE MGT9224MB-W32-IP68 030060109 TURBO FAN FOR COLOR WHEEL...
  • Page 29 MOTOR FOR TILT CONTROL PANEL 230061102 PAN DRIVER BOARD 230061107 TILT DRIVER BOARD 230061108 ENCODER BOARD 230060932 LED MODULE DRIVER BOARD (3 230061124 CHANNEL) MODULE DRIVER BOARD(4 230061101 CHANNEL) FAN SPEED ADJUSTMENT BOARD 230061106 4 CHANNEL MOTOR DRIVER BOARD 230061103 6 CHANNEL MOTOR DRIVER BOARD 230061104 8 CHANNEL MOTOR DRIVER BOARD...
  • Page 30 Guangzhou, 511442 China TEL: +86-20-3995 2888 FAX: +86-20-3995 2330 PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified if necessary. Patented Products. Counterfeiting Will be Prosecuted! P/N: 320020792...
