9.1.2 LED indication – SIO mode
LED
Q1/TAG
Q2/BUSY Yellow
ERROR
POWER
9.2 LED indication – TN-M...
9.2.1 LED indication – IO-Link mode
Indication
Green flashing (1 Hz)
Yellow
Yellow flashing (5 Hz) Tag at the limit of the detection range
9.2.2 LED indication – SIO mode
Indication
Green
Green flashing (5 Hz)
Yellow
Yellow flashing (5 Hz) Output is configured for the data update: Tag at the limit of the detec-
V01.00 | 2021/05
Indication Meaning
Yellow Output 1 active
Yellow flashing Output 1: Tag in the Data update or Tag presence operating
(5 Hz)
modes at the limit of the detection range
Output 2 active
Yellow flashing Output 2: Tag in the Data update or Tag presence operating
(1 Hz) modes at the limit of the detection range
Red Error detected
Green SIO mode active
Meaning
IO-Link mode active
Tag within the optimum detection range
Meaning
SIO mode active
Output is configured for tag detection (Tag presence): Tag at the limit
of the detection range
Output 1 active
tion range
21
