  • Page 1 Your Global Automation Partner NIC…-EM30-IOL-… Inductive Couplers Instructions for Use...
  • Page 2: Table Of Contents

    Resetting to factory settings.................. 17 Setting .............................. 18 10 Troubleshooting.......................... 19 11 Maintenance .............................  20 12 Repair .............................. 20 12.1 Returning devices ...................... 20 V01.00 | 2023/03 | 2 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com...
  • Page 3 Technical data of inductive transfer system............ 22 14.4 Ambient conditions......................  22 14.5 Design .......................... 22 15 Turck subsidiaries — contact information..................  23 V01.00 | 2023/03 | 3 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com...
  • Page 4: About These Instructions

    If you have any suggestions for improving the design or if some information is missing in the document, please send your suggestions to techdoc@turck.com. V01.00 | 2023/03 | 4 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com...
  • Page 5: Notes On The Product

    Primary side or secondary side Two M30 nuts for mounting Quick Start Guide Turck service Turck supports you with your projects, from initial analysis to the commissioning of your applic- ation. The Turck product database under www.turck.com contains software tools for program- ming, configuration or commissioning, data sheets and CAD files in numerous export formats.
  • Page 6: For Your Safety

    The product is designed according to state-of-the-art technology. However, residual risks still exist. Observe the following warnings and safety notices to prevent damage to persons and property. Turck accepts no liability for damage caused by failure to observe these warning and safety notices.
  • Page 7: Product Description

    NICS-EM30-IOL-HK1141 secondary side Properties and features Threaded barrel, M30 × 1.5 Stainless steel, 1.4404 DC 4-wire, 24 VDC +20 %/-15 % V01.00 | 2023/03 | 7 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com...
  • Page 8: Operating Principle

    The following modifications can be carried out in configuration mode: setting the inductive coupler system reading diagnostic information from the inductive coupler system V01.00 | 2023/03 | 8 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com...
  • Page 9: Foreign Object Detection (Fod)

    FOD also does not detect any metal foreign objects if the power transfer between the primary side and secondary side is negligible. V01.00 | 2023/03 | 9 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com...
  • Page 10: Technical Accessories

    TBIL- I/O hub for IO-Link, 16 universal M1-16DXP digital PNP channels M12 x 1 27,4 25,2 44,7 32,2 ø 4,3 V01.00 | 2023/03 | 10 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com...
  • Page 11 DIN 3015-1, consisting of two 40 [1.57] half shells, aluminum 59 [2.32] Ø 30 [1.18] 42 [1.65] 5 mm 1 Nm mm [Inch] V01.00 | 2023/03 | 11 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com...
  • Page 12: Installing

    Refer to tables “Angle offset” and “Lateral offset”. fig. 4: Mounting distances Distance Minimum mounting distances 60 mm 26.5 mm 30 mm 60 mm V01.00 | 2023/03 | 12 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com...
  • Page 13: Angle Offset

    Lateral offset between primary side (left) and secondary side (right) Distance D Offset M 0…4 mm 5 mm 5 mm 3 mm 7 mm 2 mm V01.00 | 2023/03 | 13 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com...
  • Page 14: Connection

    Connect the NICP… primary side via an M12 connection cable to a controller or a field- bus device as shown in the wiring diagrams. V01.00 | 2023/03 | 14 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com...
  • Page 15: Commissioning

    The connection time for the complete system is normally 1400 ms. The following measures can be taken to reduce the connection time: use of a Turck IO-Link master with the Quick startup switched on: Connection time normally 1100 ms Primary side already switched on: Connection time normally 600 ms IO-Link mode „...
  • Page 16: Operation

    Red flashing 5 Hz Primary side error Secondary side red flashing (5 Hz), behavior of the Secondary side error primary side not relevant V01.00 | 2023/03 | 16 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com...
  • Page 17: Temperature Derating

    Connect pin 5 of the secondary side with GND of the secondary side. „ Align the secondary side with the primary side (see [} 12]). The factory settings are restored. V01.00 | 2023/03 | 17 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com...
  • Page 18: Setting

    Close configuration mode: „ Write _LeaveConfigMode in the Application Specific Tag. Observe upper and lower case. „ Carry out a voltage reset. V01.00 | 2023/03 | 18 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com...
  • Page 19: Troubleshooting

    „ Wear safety gloves when removing foreign objects. „ Remove foreign objects from the active area. The device returns automatically to operating mode. V01.00 | 2023/03 | 19 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com...
  • Page 20: Maintenance

    Observe our return acceptance conditions when returning the device to Turck. 12.1 Returning devices Returns to Turck can only be accepted if the device has been equipped with a Decontamination declaration enclosed. The decontamination declaration can be downloaded from https://www.turck.de/en/retoure-service-6079.php and must be completely filled in, and affixed securely and weather-proof to the outside of the packaging.
  • Page 21: Technical Data

    7 days at 1 m depth in water) Electrical connection M12 female connector, 5-pin Min. input voltage High Level Low Level Input current < 4.5 mA V01.00 | 2023/03 | 21 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com...
  • Page 22: Technical Data Of Inductive Transfer System

    Pollution degree 3 (acc. to IEC 60947-1-2007) 14.5 Design Technical data Housing material Stainless steel, 1.4404 Material of active face V01.00 | 2023/03 | 22 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com...
  • Page 23: Turck Subsidiaries - Contact Information

    Via San Domenico 5, IT-20008 Bareggio (MI) www.turckbanner.it Japan TURCK Japan Corporation ISM Akihabara 1F, 1-24-2, Taito, Taito-ku, 110-0016 Tokyo www.turck.jp V01.00 | 2023/03 | 23 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com...
  • Page 24 Inönü mah. Kayisdagi c., Yesil Konak Evleri No: 178, A Blok D:4, 34755 Kadiköy/ Istanbul www.turck.com.tr Turck Inc. 3000 Campus Drive, USA-MN 55441 Minneapolis www.turck.us V01.00 | 2023/03 | 24 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com...
  • Page 25 Over 30 subsidiaries and 60 representations worldwide! 100040549 | 2023/03 100040549 www.turck.com...
