MVI69E-LDM-MQTT ♦ MQ Telemetry Transport
CompactLogix® Platform
4.3
MQTT Explorer Client Configuration
The MQTT Explorer client must be configured so that the data from the PLC is displayed
in the MQTT Explorer.
1
Launch MQTT Explorer. The MQTT Connection dialog displays with two default
connections.
2
Select mqtt.eclipse.org from the list of connections on the left.
3
Edit the settings in the panel on the right as follows:
o
Name: mqtt.eclipse.org
Validate certificate: Off
o
Encryption: Off
o
Protocol: mqtt://
o
Host: 137.135.83.217
o
o
Port: 1883
ProSoft Technology, Inc.
Figure 6: Initial MQTT Connection dialog
MQTT Generic Type Sample Application
Quick Start Guide
Page 17 of 54
