MVI69E-LDM-MQTT ♦ MQ Telemetry Transport
CompactLogix® Platform
Figure 2: MVI69E-LDM-MQTT SparkplugB Communication Topology
3.2
Configuring the CompactLogix PLC
1
Open the LDM_MQTT.ACD program and change the appropriate CompactLogix
chassis type to match your hardware and firmware.
2
Download LDM_MQTT.ACD file to the CompactLogix processor by choosing
C
OMMUNICATIONS
3
Install the sample application.
Note: If there is an application currently running on the MVI69E-LDM, be sure to back it up before
proceeding.
ProSoft Technology, Inc.
> W
A
> D
HO
CTIVE
OWNLOAD
Connecting to the MVI69E-LDM
.
Quick Start Guide
Page 11 of 54
