Installing Software for Remote Access

Remote access for administration can be provided over dial-up lines using an
AT&T 222+CEO (or equivalent) modem, except on the System 25 when
the same processor is used for both AUDIX Voice Power and the
Master Controller. (In this case, the serial port is connected to the switch
and is not available for connection to the modem.)
Use the following procedures to install software to drive a modem.
1 Login as root (if you are not already logged in).
2 At the # prompt, type. face and press [Enter].
3 Move the cursor to System Administration and press [Enter].
4
Move the cursor to peripheral Setup and press [Enter].
5 Move the cursor to Serial port Setup and press [Enter].
6 Populate the fields as follows:
– Serial Port Number: 01 (/dev/tty00)
– Device type: Modem
– Device Speed: Select the appropriate speed, 1200 or 2400
7
Press [F3] (SAVE).
Another screen will appear. Populate the fields as follows:
– Modem Name:
Press [F2] (CHOICES). Select the modem type that you are
installing. (The selection "Hayes Smartm 1200" should be used for
the AT&T 224-CE0 modem. " Hayes Smartm 1200" will usually
work for lower speed modems.)
Device Connection:
Press [F2] (CHOICES). Continue pressing [F2] (CHOICES) until
the field reads Incoming calls only.
8 Press [F3] (SAVE).
Press [F3] (CONT).
9
