4
Use the down arrow key to move the highlight bar to System Checkout or
Test All Modules ( the command displayed depends on the processor
that you are using) and press [Enter].
Note
If Test All Modules appears on the main menu, customization Screen
will also appear. The interactive mode must be set to on on the
Customization Screen before selecting Test All Modules if the speaker
test, floppy-disk drive test, keyboard keystrokes and typematic tests, and
mouse tests are to be performed. If the interactive mode is off, these tests
will not be performed.
5 Follow the directions on the screen to run the diagnostics.
Circuit Board Diagnostics (System 25 with IS-II)
Diagnostics for the IVP4 boards can be run after initial setup to determine
whether everything is connected properly and there is a dial tone. To run
the IVP4 board diagnostics, follow these steps:
1 At the Login: prompt, type maint and press [Enter].
2 At the Password: prompt, type the password and press [Enter].
The AT&T Integrated Solution Maintenance window is displayed.
3 Using the up and down arrow keys, move the cursor to Technician
Maintenance and press [Enter].
The Technician Maintenance window is displayed.
4 Move the cursor to Maintenance Log and press [Enter].
5 Move the cursor to IVP Board Diagnostics
The system searches for dial tones (Loop
boards and then informs you if the IVP4
IVP4 board fails you will have to replace
found, check the Tip/Ring connections.
Note
The diagnostic tests for up to eight boards (0-7). For each board that is
not present the system responds:
Can't Diagnose Card x, It is not present.
and press [Enter].
Current) on the administered
board passes the test. If the
the board. If dial tones are not
Configuration Testing and Troubleshooting 4-5
