Diagnostics

The only diagnostics that can be run at this time are those provided on the
Customer Test diskette for testing the basic system integrity. Additional
diagnostics for the IVP4 boards cannot be run until the software is installed.
To run the Customer Test diagnostics, follow these steps:
1 Insert the Customer Test disk supplied with the system into floppy disk
drive A.
2 Boot the system by turning power ON or by pressing the [Reset] button if
the power is already on.
The system boots from the Customer Test disk and displays the
Customer Test introduction screen.
3 Press [Enter] to continue.
The Customer Test main menu appears.
4 Use the Down arrow key to move the highlight bar to System Checkout or
Test All Modules (the command displayed depends on the processor
that you are using) and press [Enter].
Note
If Test All Modules appears on the main menu, Customization Screen
will also appear. The interactive mode must be set to on, on the
Customization Screen before selecting Test
test, floppy-disk drive test, keyboard keystrokes and typematic tests, and
mouse tests are to be performed. If the interactive mode is off, these tests
will not be performed.
Follow the directions on the screen to run the diagnostics.
5
if the speaker
All Modules
