2.6 PROGRAMMING AND READBACK (RS232/485, Optional IEEE Interface)
1.Vout programming accuracy (*11)
2.Iout programming accuracy
3.Vout programming resolution
4.Iout programming resolution
5.Vout readback accuracy
6.Iout readback accuracy
7.Vout readback resolution
output voltage
8.Iout readback resolution
output current
2.7 PROTECTIVE FUNCTIONS
1.Foldback protection
2.Over-voltage protection
3.Over-voltage trip point
4.Output under voltage limit
5.Over temperature protection
2.8 FRONT PANEL
1.Control functions
2.Display
3.Indications
2.9 ENVIRONMENTAL CONDITIONS
1.Operating temperature
2.Storage temperature
3.Operating humidity
4.Storage humidity
5.Altitude
2.10 MECHANICAL
1.Cooling
2.Weight
3.Dimensions (WxHxD)
4.Vibration
5.Shock
12.5
6 8 20
V
---
0.05% of rated output voltage
---
0.1%+0.1% of rated output current
---
0.002% of rated output voltage
---
0.002% of rated output current
---
0.05% of rated output voltage
---
0.3% of rated output current
% of rated
0.002%
0.002% 0.009% 0.006%
% of rated
0.011% 0.002% 0.002% 0.003%
V 6 8 12.5 20
---
Output shut-down when power supply change from CV to CC. User presetable.
---
Inverter shut-down, manual reset by AC input recycle or by OUT button or by communication port command.
V 0.5~7.5 0.5~10 1~15 1~24
Preset by front panel or communication port. Prevents from adjusting Vout below limit.
---
Does not affect analog programming.
User selectable, latched or non latched.
---
--- Vout/Iout manual adjust by separate encoders (coarse and fine adjustment).
--- OVP/UVL manual adjust by Vout. Adjust encoder.
Address selection by Voltage Adjust encoder. No of address:31.
---
Go to local control.
---
Output on/off
---
---
AC on/off
---
Front panel Lock
--- Foldback control
---
Baud rate selection: 1200, 2400, 4800, 9600 and 19200.
---
Re-start modes (automatic restart, safe mode).
---
Vout: 4 digits, accuracy: 0.05% 1count.
---
Iout: 4 digits, accuracy: 0.2% 1count.
--- VOLTAGE, CURRENT, ALARM, FINE, PREVIEW, FOLDBACK, LOCAL, OUTPUT ON.
o
0~50 C, 100% load.
---
o
-20~70 C
---
20~90% RH (no condensation).
%
% 10~95% RH (no condensation).
--- Maximum 3000m. Derate output current by 2%/100m above 2000m.
Alternatively, derate maximum ambient temperature by 1°C/100m above 2000m.
--- Forced air cooling by internal fans.
Kg Less than 4.5Kg.
W: 214.0, H: 43.6 (57.0 Benchtop Version), D: 437.5 (Refer to Outline drawing).
mm
--- MIL-810E, method 514.4, test condition I-3.3.1
--- Less than 20G, half sine, 11mS. Unit is unpacked.
10
10
40 60 80
30 100
0.004% 0.003%
0.002% 0.002% 0.011%
0.005% 0.006% 0.009% 0.002% 0.002%
30 40 60 80 100
2~36 2~44 5~66 5~88 5~110
±
±
150 600
300
0.004% 0.002%
0.007%
0.003% 0.005% 0.009%
150 300 600
5~165 5~330 5~660
