CHAPTER 2 GENH SPECIFICATIONS

2.1 OUTPUT RATING
MODEL
1.Rated output voltage ( 1) *
2.Rated output current (*2)
3.Rated output power

2.2 INPUT CHARACTERISTICS

1. AC Input voltage/freq. range (*3) (*13)
2.Input current (at 100/200Vac)
3.Power Factor
4.Efficiency (*4)
5.Inrush current at 100/200V
2.3 CONSTANT VOLTAGE MODE
1.Max. Line regulation (*5)
2.Max Load regulation (*6)
3.Ripple and noise (p-p , 20MHz) (*10)
4.Ripple r.m.s., 5Hz~1MHz (*10)
5.Temperature coefficient
6.Temperature drift
7.Rem. sense compensation/wire
8.Up-prog. response time, 0~Vomax(*9)
9.Down-prog. response time: Full load
No load
10.Transient response time
11.Hold-up time
2.4 CONSTANT CURRENT MODE
1.Max. Line regulation (*5)
2.Max. Load regulation (*7)
3.Ripple r.m.s. 5Hz~1MHz (*8)
4.Temperature coefficient
5.Temperature drift
6.Warm up drift

2.5 ANALOG PROGRAMMING AND MONITORING

1.Vout voltage programming
2.Iout voltage programming
3.Vout resistor programming
4.Iout resistor programming
5.On/off control
6.Output current monitor
7.Output voltage monitor
8.Power supply OK signal
9.Parallel operation
10.Series operation
11.CV/CC indicator
12.Enable/Disable
13.Local/Remote analog control
14.Local/Remote analog indicator
GENH 6-100 8-90 12.5-60 20-38
V 6 8 12.5 20
100 90 60 38
A
W 600 720 750 760
V 6 8 12.5 20
--- 85~265Vac continuous , 47~63Hz,single phase.
A 10.5/5
--- 0.99@100/200Vac , rated output power.
%
76/78 77/80 81/84 82/85
A Less than 25A.
V 6 8 12.5 20
0.01% of rated output voltage +2mV
---
0.01% of rated output voltage +2mV
---
60 50 60 60
mV
8 6 7 7.5
mV
50PPM/ C from rated output voltage, following 30 minutes warm-up.
PPM/C O
0.01% of rated Vout over 8hrs interval following 30 minutes warm-up. Constant line, load & temp.
---
V 1 1 1
1
mS
80
10 50
mS
500 700 800
600
mS Time for the output voltage to recover within 0.5% of its rated output for a load change 10~90% of rated
output current.
Output set-point: 10~100%.
Less than 1mS, for models up to and including 100V. 2mS, for models above 100V.
More than 20mS, 100Vac, rated output power.
mS
V 6 8 12.5 20
---
0.01% of rated output current +2mA
--- 0.02% of rated output current +5mA
mA 200 1 0 8 110 50
70PPM/ C from rated output current, following 30 minutes warm-up.
PPM/ C O O
--- 0.01% of rated Iout over 8hrs interval following 30 minutes warm-up. Constant line, load & temp.
Less than 0.1% rated output current over 30 minutes following power on or output voltage change or load
---
current change.
--- 0~100%, 0~5V or 0~10V, user select. Accuracy and linearity: ±0.5% of rated Vout.
--- 0~100%, 0~5V or 0~10V, user select. Accuracy and linearity: ±1% of rated Iout.
0~100%, 0~5/10Kohm full scale, user select. Accuracy and linearity: ±1% of rated Vout.
---
0~100%, 0~5/10Kohm full scale, user select. Accuracy and linearity: ±1.5% of rated Iout.
---
By electrical Voltage: 0~0.6V/2~15V or dry contact, user selectable logic.
---
--- 0~5V or 0~10V, user selectable. Accuracy: 1%.
---
0~5V or 0~10V, user selectable. Accuracy : 1%.
---
4~5V-OK, 0V-Fail. 500ohm series resistance.
---
Possible, up to 4 units in master/slave mode with single wire current balance connection.
---
Possible (with external diodes), up to 2 units.
---
Open collector. CC mode: On, CV mode: Off. Maximum voltage: 30V, maximum, sink current: 10mA.
--- Dry contact. Open: off, Short: on. Max. voltage at Enable/Disable in: 6V.
--- By electrical signal or Open/Short: 0~0.6V or short: Remote, 2~15V or open: Local.
---
Open co lector. Local: Open, Remote: On. Maximum voltage: 30V, maximum sink current: l
9
9
40-19 60-12.5 80-9.5 100-7.5 150-5 300-2.5 600-1.3
30-25
30 40 60 80 100
25 19 12.5 9.5 7.5
750 760 750 760 750
30 40 60 80 100
82/85 83/87 83/87 83/87 83/87
30 40 60 80 100
50 60 60 75 75
6 7 7 7 8
1.5 2 3 4 5
150
80 150
900 1000 1100 1200
1500
30 40 60 80 100
45 30 38 29 23
150 300 600
5 2.5 1.3
750 750 780
150 300 600
83/87 83/87 83/87
150 300 600
75 130 300
8 20 60
5 5 5
250
250
2000 2500 4000
150 300 600
8 6 4
10 mA.
