Croplands WEED-IT Setup Manual page 10

BOOM TRANSPORT, UNLOADING & SET-UP GUIDE
VERSION 4
22. Set boom airbag heights.
• Note this should only be done with the sprayer
on flat ground and the boom open to the spray
position. Use the quick start folding guide BT-
OMWEED-QSG-B to fold the boom out to the
working position
WEEDit – Boom Parking, Quick Start Guide (v3),
TO OPEN THE WEEDit BOOM, ready to spray >>>
1. Hold the LATCH ARMS switch DOWN
rams are retracted.
2. Fully extended both stay arms. Hold the FOLD ARM switch to the
sides are fully extended.
3. Set the BOOM STEER WHEELS switch to PART
to rotate ½ of their travel.
4. Drive forwards slowly below 5 KM/H. While moving forward, hold both the LH WHEEL & RH WHEEL
switches DOWN, this will allow the booms to move approximately out half way
• It will take approximately take 10 ~ 30 metres of travel to accomplish
this, depending on the soil conditions.
• Set the BOOM WHEELS switch back to the
Rotate the main wheels back to the original position, so they are in-line with the
boom. Hold both the LH WHEEL & RH WHEEL switches to the
• With the boom in the working position, slowly
release air evenly from both shockers (at this stage
the airbags should have 80 psi) to achieve a
camera working height of 1 100 mm.
10
BT-OMWEED-TRANS v4
• There needs to be always a minimum of 20psi in
• Both shockers in each set must be the same
to suit the 4 + 5 switchbox.
It's vital that the correct
parking procedures are
followed.
Failure to follow these
guidelines may result in
damage to the sprayer.
Perform all folding
operations on flat ground.
LH and RH Fence-line switching is via
the same switchbox. Down is OFF.
to set the latches to the Lock position. Check the locking
DOWN position until both
FOLD, this will only allow the boom wheels
23. Tension boom wheel bolts to a minimum of 235Nm
LOCK position.
(173 ft.lbs.)
UP position until done.
PTO
the shocker!
pressure
