Prepare for your network environment

This information assists you in identifying and complying with the minimum
network configuration required to set up an Operations Console local console on a
network (LAN) configuration.
Important: You need to install the LAN card for Operations Console according to
your iSeries model. To do this, see Meet Operations Console hardware
requirements. If your server is new and you ordered a local console on a network
configuration, the card should already be configured with the server. The LAN
card should be a dedicated LAN adapter for service tools.
Network security
IBM recommends treating the console over a LAN connection with the same
physical security considerations and controls as a local console directly attached to
the server or a twinaxial console. For instance, consider configuring a local console
on a network in a network separate from the main network (or the company
intranet) and strictly control access to the machine acting as the console.
BOOTstrap Protocol
An Operations Console local console on a network uses the BOOTstrap Protocol
(BOOTP) to configure the iSeries service IP communications stack. The IP stack
configuration plus iSeries serial number is requested in the Operations Console
configuration wizard. The iSeries broadcasts a BOOTP request. The Operations
Console PC replies with the information submitted during the configuration
wizard. The iSeries then stores and uses the configuration information for the
service IP communications stack.
Notes:
1. The Operations Console PC must be placed on a network that is accessible by
the iSeries. This can be the same physical network or a network that permits
broadcast packets to flow. This is a one-time setup requirement; normal console
operation does not require this. It is recommended that this setup occur on the
same physical network.
2. The BOOTP request carries the iSeries serial number. The iSeries serial number
is used to assign the IP configuration information. If you are having problems
configuring the service IP communications stack, check that the Operations
Console PC is on the same physical network and the iSeries serial number is
correct in the configuration.
3. Operations Console local console on a network uses ports 2323 and 3001. To
use Operations Console in a different physical network the router and firewall
must allow IP traffic on these ports.
The success of BOOTP is dependent on the network hardware used to connect
4.
the iSeries and the PC. In some cases you may need an alternate console device
to configure the connection in DST. To use BOOTP the network hardware used
must be capable of AutoNegotiation of Speed and Duplex if using the 2838
Ethernet Adapter for the console connection.

Secure your Operations Console configuration

Operations Console security consists of service device authentication, user
authentication, data privacy, and data integrity. Operations Console local console
directly attached to the server has implicit device authentication, data privacy, and
data integrity due to its point-to-point connection. User authentication security is
required to sign on to the console display.
