Enclosure Dimensions; View From Back; View From Front - Altronix R2432600UL Quick Start Manual

3.125"
32 31 30
N P N P N
8.5"
.75"
Altronix Corp. - 140 58th Street, Brooklyn, NY 11220 • 718-567-8181 • 888-258-7669 • altronix.com

Enclosure Dimensions

3.25"H x 19.125"W x 8.5"D

View from back

29 28 27 26 25 24 23 22 21
P N P N P N P N P N P N P N P N P N P

View from front

BACK
20 19 18 17 16 15 14 13 12 11
N P N P N P N P N P N P N P N P N P N P
17.625"
BOTTOM
FACEPLATE
19.125"
10 9 8 7 6 5 4 3 2 1
N P N P N P N P N P N P N P N P N P N P
