Altronix R2432600UL Quick Start Manual

• Input 115VAC, 50/60Hz, 3 amp.
• 24VAC @ 25 amp (600VA) or
28VAC @ 20 amp (560VA) supply current.
• Illuminated power disconnect circuit breaker
with manual reset.
• Surge suppression.
• Removable terminal blocks w/locking screw flanges.
• 3-wire grounded line cord.
• Individual power LEDs.
• Spare fuse(s) provided (fuse protected model only).
• Unit maintains camera synchronization.
UL Listed for Commercial CCTV Equipment
(UL 2044).
R2432600UL, R2432600ULCB UL Listed
Rack Mount CCTV Power Supply

Overview

• These Altronix AC Rack Mount CCTV Power Supplies provide 24VAC or
28VAC distributed via thirty-two (32) fuse or Class 2 Rated PTC protected
power limited outputs for powering CCTV Cameras, heaters and
other video accessories.
R2432600UL
• Thirty-two (32) fuse
protected outputs.
• Outputs are rated @ 3.5 amp.

Specifications

• Ease of installation saves time and eliminates
• 2U rack mount chassis for use in standard
• Product weight:
• Shipping weight:

Agency Approvals

R2432600ULCB
• Thirty-two (32) Class 2 Rated PTC
protected power limited outputs.
• Outputs are rated @ 2.5 amp.
costly labor.
EIA 19" rack.
- ALTV2432600UL: 23.0 lbs.
- ALTV2432600ULCB: 22.9 lbs.
- ALTV2432600UL: 24.0 lbs.
- ALTV2432600ULCB: 23.9 lbs.
CUL Listed - CSA Standard C22.2 No.1-98,
Audio, Video and Similar Equipment.
Rev. DSR2432600UL - B10F
