R2432220 Series
Rack Mount CCTV Power Supplies
Installation Guide
Models Include:
R2432300220
- 24VAC @ 12.5A (300VA) or
28VAC @ 10A (280VA).
- Thirty-Two (32) Fuse Protected Outputs.
R2432600220
- 24VAC @ 25A (600VA) or
28VAC @ 20A (560VA).
- Thirty-Two (32) Fuse Protected Outputs.
Rev. 111605
R2432300CB220
- 24VAC @ 12.5A (300VA) or
28VAC @ 10A (280VA).
- Thirty-Two (32) PTC Protected Outputs.
R2432600CB220
- 24VAC @ 25A (600VA) or
28VAC @ 20A (560VA).
- Thirty-Two (32) PTC Protected Outputs.
More than just power.
TM
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Altronix R2432220 Series
Summary of Contents for Altronix R2432220 Series
-
Page 1: Installation Guide
R2432220 Series Rack Mount CCTV Power Supplies Installation Guide Models Include: R2432300220 R2432300CB220 - 24VAC @ 12.5A (300VA) or - 24VAC @ 12.5A (300VA) or 28VAC @ 10A (280VA). 28VAC @ 10A (280VA). - Thirty-Two (32) Fuse Protected Outputs. - Thirty-Two (32) PTC Protected Outputs. -
Page 2: Specifications
Overview: Altronix R2432220 Series Rack Mount CCTV Power Supplies provide 24VAC or 28VAC distributed via thirty- two (32) fuse or PTC protected outputs for powering CCTV cameras, heaters and other video accessories. Thirty-Two (32) Output Rack Mount Configuration Reference Chart:... - Page 3 Blown fuse (R2432300220 and R2432600220) - Set power switch on back of unit to the OFF position (Fig. 1c, pg. 3). Remove front faceplate to access fuses. Replace with fuses rated @ 3.5A/250VA (Altronix model # Fuse1). b. Tripped PTC (R2432300220 and R2432600CB220) - To reset PTC, set power switch on back of unit to the OFF position.
-
Page 4: Rear View
N P N P Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. MEMBER IIR2432220 Rack Mount Series...
