Altronix Rack Mount Series Installation Manual
Ul listed cctv power supplies
Hide thumbs
Also See for Rack Mount Series:
- Installation manuals (4 pages) ,
- Installation manual (12 pages)
Advertisement
Quick Links
Rack Mount Series
UL Listed CCTV Power Supplies
Installation Guide
Models Include:
• R2416UL
- 24VAC @ 7 amp (175VA).
- Sixteen (16) Fuse Protected Outputs.
• R2416300UL
- 24VAC @ 12.5 amp (300VA).
or 28VAC @ 10 amp (280VA).
- Sixteen (16) Fuse Protected Outputs.
• R2416600UL
- 24VAC @ 25 amp (600VA).
or 28VAC @ 20 amp (560VA).
- Sixteen (16) Fuse Protected Outputs.
• R2416ULCB
- 24VAC @ 7 amp (175VA).
- Sixteen (16) PTC Protected Outputs.
• R2416300ULCB
- 24VAC @ 12.5 amp (300VA).
or 28VAC @ 10 amp (280VA).
- Sixteen (16) PTC Protected Outputs.
• R2416600ULCB
- 24VAC @ 25 amp (600VA).
or 28VAC @ 20 amp (560VA).
- Sixteen (16) PTC Protected Outputs.
Rev. 020504
Advertisement
Related Manuals for Altronix Rack Mount Series
Summary of Contents for Altronix Rack Mount Series
- Page 1 Rack Mount Series UL Listed CCTV Power Supplies Installation Guide Models Include: • R2416UL • R2416ULCB - 24VAC @ 7 amp (175VA). - 24VAC @ 7 amp (175VA). - Sixteen (16) Fuse Protected Outputs. - Sixteen (16) PTC Protected Outputs.
- Page 2 Overview: These Altronix Rack Mount CCTV Power Supplies provide 24VAC or 28VAC distributed via sixteen (16) fuse or PTC protected outputs for powering CCTV Cameras, heaters and other video accessories. Sixteen (16) Output Rack Mount Configuration Reference Chart: Altronix Model Number...
- Page 3 Blown fuse (R2416UL, R2416300UL & R2416600UL) - Set power switch on back of unit to the OFF position (Fig. 1C, pg. 3). Remove front faceplate to access fuses. Replace with fuses rated @ 3.5A/250VA (Altronix model # Fuse1). b. Tripped PTC (R2416ULCB, R2416300ULCB & R2416600ULCB) - To reset PTC, set power switch on back of unit to the OFF position.
- Page 4 FACEPLATE 19.125" .75" Altronix is not responsible for any typographical errors. Altronix Corp. 140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056 web site: www.altronix.com, e-mail: info@altronix.com, Lifetime Warranty, Made in U.S.A. IIR2416ULRackMountSeries B05D MEMBER - 4 -...
