R248220 Series
Rack Mount CCTV Power Supplies
Installation Guide
Models Include:
R248220
- 24VAC @ 4A (100VA) or
28VAC @ 3.5A (100VA).
- Eight (8) Fuse Protected Outputs.
R248300220
- 24VAC @ 14A (350VA) or
28VAC @ 12.5A (350VA).
- Eight (8) Fuse Protected Outputs.
R248600220
- 24VAC @ 25A (600VA) or
28VAC @ 20A (600VA).
- Eight (8) Fuse Protected Outputs.
Rev. 111605
R248CB220
- 24VAC @ 4A (100VA) or
28VAC @ 3.5A (100VA).
- Eight (8) PTC Protected Outputs.
R248300CB220
- 24VAC @ 14A (350VA) or
28VAC @ 12.5A (350VA).
- Eight (8) PTC Protected Outputs.
R248600CB220
- 24VAC @ 25A (600VA) or
28VAC @ 20A (600VA).
- Eight (8) PTC Protected Outputs.
More than just power.
TM
Advertisement
Related Manuals for Altronix R248220 Series
Summary of Contents for Altronix R248220 Series
- Page 1 R248220 Series Rack Mount CCTV Power Supplies Installation Guide Models Include: R248220 R248CB220 - 24VAC @ 4A (100VA) or - 24VAC @ 4A (100VA) or 28VAC @ 3.5A (100VA). 28VAC @ 3.5A (100VA). - Eight (8) Fuse Protected Outputs. - Eight (8) PTC Protected Outputs.
- Page 2 Overview: Altronix R248220 Series Rack Mount CCTV Power Supplies provide 24VAC or 28VAC distributed via eight (8) fuse or PTC protected outputs for powering CCTV cameras, heaters, and other video accessories. Eight (8) Output Rack Mount Configuration Reference Chart: Individual...
- Page 3 Line Cord Block Illuminated Power Disconnect Circuit Breaker with manual reset XFMR XFMR Used on PTC Models Fig. 1d 24VAC Output (Factory Set) 28VAC Output AC Power AC Power LEDs LEDs Green Wire Earth GND R248220 Series - 3 -...
- Page 4 N P N P Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. MEMBER IIR248220 Rack Mount Series...
