Summary of Contents for Advantech POC-W24 Series
- Page 1 User Manual POC-W24 Series Point-of-Care Terminal with Intel® Core™ i7 Processor, and a 23.8" TFT LCD...
- Page 2 Repair of the device may also only be carried out by trained service personnel. Advantech recommends that a service contract be obtained with Advantech Service and that all repairs also be carried out by them. Otherwise the correct functioning of the device may be compromised.
- Page 3 Discard used batteries according to the manufacturer’s instructions Caution! The battery charging Indicator Is not Included In this device, and It shall be added In the end system assembly and be shown In the end system. POC-W24 Series User Manual...
- Page 4 Caution! When servicing the device, always use replacement parts that are quali- fied to Advantech standards. Advantech Medical cannot warrant or endorse the safe performance of third-party replacement parts for use with our medical device.
- Page 5 ISO 7000-0434 : Caution, consult ACCOMPANYING DOCUMENTS. ISO 7000-1641 : Follow operating instructions or Consult instructions for use. IEC 60417 -5009 : STAND-BY. IEC 60417-5031 : Direct current. IEC 60417-5021 : Equipotentiality. ISO 7010-M002: Follow instructions for use POC-W24 Series User Manual...
- Page 6 Consult the dealer or an experienced radio/TV technician for help Warning! Any changes or modifications made to the equipment which are not expressly approved by the relevant standards authority could void your authority to operate the equipment. POC-W24 Series User Manual...
- Page 7 Otherwise the correct functioning of the device may be compromised. Additional Information and Assistance Contact your distributor, sales representative, or Advantech's customer service cen- ter for technical support if you need additional assistance. Please have the following information ready before you call: ...
- Page 8 POC-W24 Series User Manual viii...
- Page 9 ......1 Introduction ....................2 Specifications .................... 2 Dimensions ....................4 Figure 1.1 Dimensions of the POC-W24 SERIES ....... 4 Figure 1.2 VESA Mounting of the POC-W24 Series....4 Figure 1.3 POC-W24 Series Front Panel ........5 1.3.1 Optional modules ................5 1.3.2...
- Page 10 POC-W24 Series User Manual...
- Page 11 Chapter General Information...
- Page 12 COM ports, quad USB 2.0 ports and a 24-bit stereo audio control- ler. With an optional 2.5" SATA drive, the POC-W24 SERIES is a user-friendly com- puter. For system integrators, this highly integrated multimedia system lets you easily build a Point-of-Care Terminal into your applications.
- Page 13 100x100, 75x75 Windows 7/Windows 8.1 Industry Pro/Windows Operating System 10 IoT Memory Up to 32GB DDR4 SODIMM x 2 Storage 2.5”SATA3 SSD 128 GB, 5V/1.5A Optional Configuration Bluetooth RTC battery Panasonic BR2032 Touch Panel 23.8'' PCTSP POC-W24 Series User Manual...
- Page 14 Figure 1.1 Dimensions of the POC-W24 SERIES VESA Mounting: 75 x 75 mm; 100 x 100 mm Please use M4x12L (Maximum) screw. Figure 1.2 VESA Mounting of the POC-W24 Series Warning! Use suitable mounting apparatus to avoid risk of injury. POC-W24 Series User Manual...
- Page 15 Figure 1.3 POC-W24 Series Front Panel Power Volume Down/Up Touchscreen Status Control Read Light Control Brightness Decrease / Increase 1.3.1 Optional modules Memory: Up to 32GB DDR4 SODIMM x 2 2.5" SATA HDD(65 degree)/SSD, mini-PCIe mSATA Touchscreen: Projected Capacitive 1.3.2...
- Page 16 One arm / hand system capable of guiding and holding device – Average degree of aging-related short term memory impairment – impaired by 40 % resulting in 60 % of normal hearing at 500 Hz to 2 kHz POC-W24 Series User Manual...
- Page 17 Chapter System Setup...
- Page 18 A Quick Tour of the POC-W24 Series Before you start to set up the POC-W24 SERIES, take a moment to become familiar with the locations and purposes of the controls, drives, connections and ports, which are illustrated in the figures below.
- Page 19 Ethernet port, USB ports and so on.) Figure 2.2 Rear view of the Point of Care Terminal Figure 2.3 Rear view of Multi I/O ports Note! Equipotential terminal need link to hospital ground/earth system before system boot to protect operator and system. POC-W24 Series User Manual...
- Page 20 If medical adaptor is connected to the POC-W243, the customer must ensure legal and regulatory compliance and that the device meets the law and standards compliance requirements of this hardware. POC-W24 Series User Manual...
- Page 21 2.8) Running the BIOS Setup Program Your POC-W24 SERIES was probably set up and configured by your dealer prior to delivery. You may still find it necessary to use the BIOS (Basic Input-Output System) setup program to change system configuration information, such as the current date and time or your type of hard drive.
- Page 22 3. Power LED ON but no DC power output 4. AC power in and all switches ON, but system doesn't power on Contact your distributor, sales representative, or Advantech's customer service cen- ter for technical support if you need additional assistance. Please have the following information ready before you call: ...
- Page 23 Guidance and manufacturer’s declaration – electromagnetic emissions The model POC-W24 Series is intended for use in the electromagnetic environment speci- fied below. The customer or the user of the model POC-W24 Series should assure that it is used in such an environment.
- Page 24 Guidance and manufacturer’s declaration – electromagnetic immunity POC-W24 SERIES is intended for use in the electromagnetic environment specified below. The customer or the user of the model POC-W24 SERIES should assure that it is used in such an environment. IEC 60601 test...
- Page 25 Guidance and manufacturer’s declaration – electromagnetic immunity The model POC-W24 SERIES is intended for use in the electromagnetic environment specified below. The customer or the user of the model POC-W24 SERIES should assure that it is used in such an environment.
- Page 26 RF transmitters, an electromagnetic site survey should be consid- ered. If the measured field strength in the location in which the model POC-W24 Series is used exceeds the applicable RF compliance level above, the model POC-W24 Series should be observed to verify normal operation.
- Page 27 Chapter Operation and Safety...
- Page 28 Thermal The vent hole of the POC-W24 SERIES rear cover functions as a cooling air flow inlet and outlet. These air inlets and outlets transfer heat from inside the computer to the cooler air outside. Do not block these holes/vents with any soft material.
- Page 29 Never place anything on system case before turning off the computer. Never turn on your computer unless all of its internal and external parts are in place. Operating the computer when it is open or missing parts can be danger- ous and can damage POC-W24 Series User Manual...
- Page 30 POC-W24 Series User Manual...
- Page 31 Appendix POC-W24 Series VESA Mounting...
- Page 32 PC into their system. Never use mounting brackets except as provided by Advantech to prevent unreliable mounting of the POC-W24 Series. VESA mount installation should be carried out by a professional technician; please contact a service technician or your retailer if you need this service.
- Page 33 POC-W24 Series User Manual...
- Page 34 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2017...
