Summary of Contents for Advantech POC-W211
- Page 1 User Manual POC-W211 Point-of-Care Terminal with Intel® Core™ i7 or i3 Processor and a 21.5" TFT LCD...
- Page 2 Repair of the device may only be carried out by trained service personnel. Advantech recommends that a service contract be obtained with Advantech Service and that all repairs also be carried out by them. Otherwise the correct functioning of the device may be compromised.
- Page 3 Discard used batteries according to the manufacturer’s instructions. Caution! The battery charging indicator is not included with this device. It will be added to the finished system assembly and be shown with the com- pleted system. POC-W211 User Manual...
- Page 4 Caution! When servicing the device, always use replacement parts that are quali- fied to Advantech standards. Advantech Digital Healthcare cannot war- rant or endorse the safe performance of third-party replacement parts for use with our medical device.
- Page 5 IEC 60878 and ISO 3864-B.3.6 : Warning: dangerous voltage ISO 7000-0434 : Caution, consult ACCOMPANYING DOCUMENTS. ISO 7000-1641 : Follow operating instructions or consult instructions for use. IEC 60417 -5009 : STAND-BY. IEC 60417-5031 : Direct current. IEC 60417-5021 : Equipotentiality. POC-W211 User Manual...
- Page 6 Consult the dealer or an experienced radio/TV technician for help Warning! Any changes or modifications made to the equipment which are not expressly approved by the relevant standard’s authority could void your authority to operate the equipment. POC-W211 User Manual...
- Page 7 Otherwise the correct functioning of the device may be compromised. Additional Information and Assistance Contact your distributor, sales representative, or Advantech's customer service cen- ter for technical support if you need additional assistance. Please have the following information ready before you call: ...
- Page 8 POC-W211 User Manual viii...
-
Page 9: Table Of Contents
......1 Introduction ....................2 Specifications .................... 2 Dimensions ....................4 Figure 1.1 Dimensions of the POC-W211 ........4 Figure 1.2 VESA Mounting of the POC-W211......4 Figure 1.3 POC-W211 Front Panel..........5 Figure 1.4 POC-W211 Back I/O ..........5 1.3.1 Optional Modules ................ - Page 10 Front Bezel Button......39 Introduction ..................... 40 8.1.1 Front Button Map ................ 40 Chapter POC-W211 Advanced BIOS Function Introduction ..................... 42 Appendix A POC-W211 VESA Mounting....45 Install VESA Mounting ................46 Figure A.1 VESA Mounting 75x75mm, 100x100 mm ....46...
-
Page 11: Chapter 1 General Information
Chapter General Information... -
Page 12: Introduction
COM ports, quad USB 2.0 ports and a 24-bit stereo audio control- ler. With an optional 2.5" SATA drive, the POC-W211 is a user-friendly computer. For system integrators, this highly integrated multimedia system lets you easily build a Point-of-Care Terminal into your applications. - Page 13 20G peak acceleration (11ms duration) Dimensions 550 x 370 x 65 mm (13.70" x 11.22" x 3.62") Physical (W x H x D) Characteristics Weight 7 kg (15.24 lb.) Platform & utility XP Professional, Windows 7, SUSI POC-W211 User Manual...
-
Page 14: Dimensions
COM1 COM2 HDMI DCIN Figure 1.1 Dimensions of the POC-W211 VESA Mounting: 75 x 75 mm; 100 x 100 mm Figure 1.2 VESA Mounting of the POC-W211 Warning! Use suitable mounting apparatus to avoid risk of injury. POC-W211 User Manual... -
Page 15: Figure 1.3 Poc-W211 Front Panel
Figure 1.3 POC-W211 Front Panel Power (B.C) Volume Down/Up Touchscreen Status Control Read Light Control (F.G) Brightness Decrease / Increase Figure 1.4 POC-W211 Back I/O Power DC-IN USB ports VGA port HDMI out port 2 x Gigabit Ethernet interface (RJ-45) -
Page 16: Point-Of-Care Terminal Cleaning And Disinfecting
Do not use disinfectants that contain phenol. Do not autoclave or clean the POC or its peripherals with strong aromatic, chlorinated, ketone, ether, or Esther solvents, sharp tools or abrasives. Never immerse electrical connectors in water or other liquids. POC-W211 User Manual... -
Page 17: Chapter 2 System Setup
Chapter System Setup... -
Page 18: A Quick Tour Of The Poc-W211
A Quick Tour of the POC-W211 Before you start to set up the POC-W211, take a moment to become familiar with the locations and purposes of the controls, drives, connections and ports, which are illus- trated in the figures below. -
Page 19: Bottom View
I/O section is at the bottom of the panel PC, as shown in Figure 2.3 and Fig- ure 2.4 (zoom view). (The I/O section includes various I/O ports, including serial ports, VGA, HDMI, Ethernet port, USB ports and so on.) (10) Figure 2.3 Rear view of the Point-of-Care Terminal POC-W211 User Manual... -
Page 20: Figure 2.4 Rear View Of Multi I/O Ports
COM1 serial ports (18) Equipotential terminal Note! Equipotential terminals need a link to hospital ground/earth system before the system boots to protect operator and system. 2.1.4 Left-side View (18) Figure 2.5 Left side View Left-side View: (18) RW-DVD-ROM (Optional) POC-W211 User Manual... -
Page 21: Right-Side View
Connect the female end of the power cord to the DC power adapter. Connect the 3-pin male plug of the power cord to an electrical outlet. Warning! The POC-W211 is supplied by a 100 watt power supply and a special adapter as depicted as above model. -
Page 22: Figure 2.7 Connecting The Power Cord
Switching on the power: Push down the power button on the front panel for POC-W211. (The color indicator turns green) Figure 2.7 Connecting the Power Cord 2.2.2 Connecting the Ground Pin With system ready, find the equipotential terminal on the rear side of the POC. -
Page 23: Running The Bios Setup Program
Running the BIOS Setup Program Your POC-W211 was probably set up and configured by your dealer prior to delivery. You may still find it necessary to use the BIOS (Basic Input-Output System) setup program to change system configuration information, such as the current date and time or your type of hard drive. -
Page 24: Table 2.1: The File Directory On "Drivers And Utilities" Cd-Rom
Install Sequence Folder Name Note Chipset Please install chipset driver first. Graphics Audio Please install internal resistive touch control- Touch ler to COM6. Please install optional device in related Option folder Note! These WIN7 drivers are all 64-bit version. POC-W211 User Manual... - Page 25 Guidance and Manufacturer’s Declaration – Electromagnetic Emissions The model POC-W211 is intended for use in an electromagnetic environment as specified below. The customer or the user of the POC-W211 should assure that it is used in such an environment. Electromagnetic Environmen-...
- Page 26 Portable and Mobile RF Communications Equipment and the POC-W211 POC-W211 is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the model POC-W211 can help prevent electromagnetic interference by maintaining a minimum distance between portable...
- Page 27 Guidance and Manufacturer’s Declaration – Electromagnetic Immunity POC-W211 is intended for use in the electromagnetic environment specified below. The customer or the user of the model POC-W211 should assure that it is used in such an envi- ronment. IEC 60601 Test...
- Page 28 Guidance and Manufacturer’s Declaration – Electromagnetic Immunity The model POC-W211 is intended for use in the electromagnetic environment specified below. The customer or the user of the model POC-W211 should assure that it is used in such an environment. Immunity...
- Page 29 RF transmitters, an electromagnetic site survey should be consid- ered. If the measured field strength in the location in which the POC-W211 is used exceeds the applicable RF compliance level above, the POC-W211 should be observed to verify normal operation.
- Page 30 POC-W211 User Manual...
-
Page 31: Chapter 3 Driver Installation
Chapter Driver Installation... -
Page 32: Introduction
Introduction The POC-W211 supports "one key" driver installation. User can just click one button to install all drivers. Warning! Please use clean OS to install this auto installation, otherwise, it might cause un-expect error. Automatic Driver Installation Double Click "InstallAll.exe" in D:\Driver\ folder. The Install dialog will appear. -
Page 33: Chapter 4 Utilities And Hot Fixes
Chapter Utilities and Hot Fixes... -
Page 34: Introduction
Introduction The POC-W211 system needs specific utilities or hot fixes to support special func- tions. Wakeup by External USB Device at S3 Resume (Wakeup) POC-W211 supports three different sleep (suspend) modes; they are: S1: Power On Suspend: system will stop the clock, turn off LCD backlight, but keep all power on. -
Page 35: Chapter 5 Operation And Safety Information
Chapter Operation and Safety Information... -
Page 36: General Safety Guide
Thermal The vent hole of the POC-W211 rear cover functions as a cooling air flow inlet and outlet. These air inlets and outlets transfer heat from inside the computer to the cooler air outside. Do not block these holes/vents with any soft material. - Page 37 Never place anything on system case before turning off the computer. Never turn on your computer unless all of its internal and external parts are in place. Operating the computer when it is open or missing parts can be danger- ous and can damage your computer. POC-W211 User Manual...
- Page 38 POC-W211 User Manual...
-
Page 39: Pcm-8709 Connector Map And Table
Chapter PCM-8709 Connector Map and Table... -
Page 40: Motherboard Top Side
Motherboard Top Side Motherboard Bottom Side POC-W211 User Manual... -
Page 41: Table 6.1: Mb Connector Table
RTC Battery Connector Power Button (Reserved) USB (Reserved) Right Speaker Connector Left Speaker Connector PCIex1 Slot EC Debug Port (Reserved) 12V (Reserved) Bluetooth Connector I/O Board Slot I/O Board * All connectors are located on the top side POC-W211 User Manual... -
Page 42: Table 6.2: I/O Connector Table
Table 6.2: I/O Connector Table Description USB Connector (Reserved) USB Connector Internal Backup Battery Connector DCIN USB I/O Reset EC Button HDMI LAN1 (iAMT) LAN2 COM2 COM1 POC-W211 User Manual... -
Page 43: Pcm-8709 Jumper Settings
Chapter PCM-8709 Jumper Settings... -
Page 44: Motherboard
Motherboard * All Jumpers located at top side Figure 7.1 PCM-8709 Motherboard Top Side I/O Board * All Jumpers located at top side Figure 7.2 PCM-8709 I/O Top Side POC-W211 User Manual... -
Page 45: Table 7.1: Jumper Settings
COM1 RS-232/422/485 output type setting Table 7.2: CN: Clear CMOS Setting Function (1-2) Clear CMOS Setup (No Connect) Normal Operation (Default) Table 7.3: CN2: Clear ME Setting Function (1-2) Clear ME Setup (No Connect) Normal Operation (Default) POC-W211 User Manual... -
Page 46: Table 7.4: Cn3: Vbios Setup
Setting Function (7-8) Set VGA as main display at bootup (No Connect) Set LVDS as main display at bootup (Default) Table 7.6: CN4: ME Manufacturing Mode Setting Function (1-2) ME Manufacturing Mode (No Connect) Normal Operation (Default) POC-W211 User Manual... -
Page 47: Table 7.7: Cn8: System Reset
(1-2) LVDS Power use 5V (Default) (2-3) LVDS Power use 3.3V Table 7.9: CN12 (IO): COM1 RS-232/422/485 Output Type Settings Setting Function (5-6), (7-9), (8-10), RS-232 (Default) (13-15), (14-16) (3-4), (9-11)(10-12), RS-422 (15-17)(16-18) (1-2), (9-11)(10-12), RS-485 (15-17)(16-18) POC-W211 User Manual... - Page 48 POC-W211 User Manual...
-
Page 49: Front Bezel Button
Chapter Front Bezel Button... -
Page 50: Introduction
LCD backlight will turn off. Pressing both buttons again for a half second will turn on the LCD backlight. When the backlight is off, the POC-W211 system will still run. There will not be an impact to any operating programs. -
Page 51: Poc-W211 Advanced Bios Function
Chapter POC-W211 Advanced BIOS Function... -
Page 52: Introduction
Introduction This section introduces the advanced functions of the POC-W211 BIOS menu. Power Button Function Enable/Disable You can enable/disable power button functions from the BIOS menu. If you disable the power button in S0 (System ON) status, the power button will not work. - Page 53 BIOS Menu location: BIOS Menu - Boot - Setup Popup Menu F12 Enable: Press F12 key at bootup displays popup menu (Default) Disable: Press F12 key at bootup does not display popup menu POC-W211 User Manual...
- Page 54 POC-W211 User Manual...
-
Page 55: Poc-W211 Vesa
Appendix POC-W211 VESA Mounting... -
Page 56: Install Vesa Mounting
PC into their system. Never use mounting brackets except as provided by Advantech to prevent unreliable mounting of the POC-W211. VESA mount installation should be carried out by a pro- fessional technician; please contact a service technician or your retailer if you need this service. - Page 57 POC-W211 User Manual...
- Page 58 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2012...
