Page 1: User Manual
POC-195 Point-of-Care Terminal with 19" TFT LCD User Manual... - Page 2 No part of this man- ual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reli- able.
-
Page 3: Declaration Of Conformity
Declaration of Conformity FCC Class B This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harm- ful interference when the equipment is operated in a residential environ- ment. - Page 4 Additional Information and Assistance Visit the Advantech websites at www.advantech.com or www.advantech.com.tw where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's cus- tomer service center for technical support if you need additional assistance.
-
Page 5: Packing List
Packing List Before installing your Point of Care Terminal, ensure that the following materials have been received: • POC-195 series Point of Care Terminal • User manual • Accessories for POC-195 – Y-shaped adapter for PS/2 mouse and keyboard – Power cord (1.8 m) - USA type (UK, German types are avail- able on request) –... - Page 6 IMPROPER INSTALLATION OF VESA MOUNTING CAN RESULT IN SERIOUS PERSONAL INJURY! VESA mount installation should be operated by professional technician, please contact the service technician or your retail if you need this service. POC-195 User Manual...
- Page 7 CLASSIFICATION: Supply Class I adapter No applied part IPX1 Continuous Operation Not AP or APG category Disconnect device: Appliance inlet. Follow the national requirement to dispose unit. Maintenance: to properly maintain and clean the surfaces, use only the approved products or clean with a dry applicator. Contact information: No.1, Alley 20, Lane 26, Reuiguang Road Neihu District, Taipei, Taiwan 114, R.O.C.
- Page 8 The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70dB (A). DISCLAIMER This set of instructions is given according to IEC 704-1. Advantech dis- claims all responsibility for the accuracy of any statements contained herein.
-
Page 9: Table Of Contents
Dimensions................ 7 Figure 1.1 Dimensions of the POC-195..... 7 Chapter 2 System Setup...........10 A Quick Tour of the POC-195 ........10 Figure 2.1 Front View..........10 Figure 2.2 Left side view ......... 10 Figure 2.3 Rear view..........11 Installation Procedures ............ 12 2.2.1... - Page 10 Installation of Touchscreen Driver........29 5.2.1 Installation for Windows XP ........29 Further Information ............35 Chapter 6 PCI Express Ethernet Interface....38 Introduction ..............38 Installation of Ethernet Driver......... 38 6.2.1 Installation for Windows XP ........38 Further Information ............40 POC-195 User Manual...
-
Page 11: General Information
General Information This chapter provides an overview of the POC-195. Sections include: • Introduction • Specifications • Cleaning/Disinfecting • LCD Specifications • Dimensions... -
Page 12: Chapter 1 General Information
Ethernet controller, multiple COM port interfaces and 18-bit stereo audio controller. With a built-in CD-ROM drive and mini PCI expansion slot, the POC-195 is as compact and user-friendly as a notebook computer. For system integrators, this simple, complete and highly integrated multime- dia system lets you easily build a Point of Care Terminal into your appli- cations. -
Page 13: Standard Pc Functions
1.2.2 Standard PC functions • CPU: Socket 479 Intel Pentium Mobile up to 2.0 GHz • BIOS: Award 512 KB flash BIOS supports Plug & Play and APM • Chipset: Intel 915GM GMCH, 82801FBM (ICH6-M) • Front side Bus: FSB 533/400 MHz •... -
Page 14: Audio Function
CD-ROM drive: Compact 24X CD-ROM or above • COMBO drive: Compact 8X DVD-ROM, 24X CD-ROM, 24X CD-R, 24X CD-RW • DVD-RW drive: Compact 8X DVD-ROM, 24X CD-ROM, 24X CD-R, 10X CD-RW, 4X DVD-RW • Mini PCI WLAN module: 802.11b/g WLAN POC-195 User Manual... -
Page 15: Touchscreen (Optional)
1.2.7 Touchscreen (optional) Table 1.1: Touchscreen specifications Type Analog Resistive Resolution Continuous Light Transmission Controller RS-232 interface (uses COM4) Power Consumption +5 V @ 200 mA Software Driver Supports Windows 2000/XP Durability (touches in a lifetime) 30 million Note The optional touchscreen uses the COM4 port. Once the touchscreen is installed, COM4 cannot be used for other purposes. -
Page 16: Cleaning/Disinfecting
Agents: Green tinctured soap and Enzymatic detergents Steps: Prepare agent according to the manufacturer's instructions or hospi- tal protocol. Wipe the POC-195 with a clean cloth that has been moistened in the cleaning solution. Wipe thoroughly with a clean cloth. Caution! Do not immerse or rinse the POC-195 and its peripherals. -
Page 17: Dimensions
1.5 Dimensions Figure 1.1: Dimensions of the POC-195 Chapter 1... - Page 18 POC-195 User Manual...
- Page 19 System Setup This chapter describes installation of POC-195. Sections include: • A Quick Tour of the POC-195 • Installation Procedures • Running the BIOS Setup Pro- gram • Installing System Software • Installing the Drivers...
-
Page 20: Chapter 2 System Setup
System Setup 2.1 A Quick Tour of the POC-195 Before you start to set up the POC-195, take a moment to become famil- iar with the locations and purposes of the controls, drives, connections and ports that are illustrated in the figures below. -
Page 21: Figure 2.3 Rear View
When you turn the Point of Care Terminal around and look at its rear cover, you will find the PCI expansion slot located on the left side. This slot is covered by a side panel cover. The sunken I/O section is at the bot- tom of the panel PC, as shown in Figure 2-3. -
Page 22: Installation Procedures
Connecting the keyboard and mouse Connect the Y-shaped adapter to the PS/2 mouse and keyboard port on the I/O section of the POC-195. Connect the PS/2 mouse and keyboard to the Y-shaped adapter. If you use a serial mouse, you can connect the mouse to any COM port in the I/O section. -
Page 23: Running The Bios Setup Program
2.3 Running the BIOS Setup Program Your POC-195 is likely to have been properly set up and configured by your dealer prior to delivery. You may still find it necessary to use the BIOS (Basic Input-Output System) setup program to change system con- figuration information, such as the current date and time or your type of hard drive. -
Page 24: Installing The Drivers
CD-ROM is: Figure 2.5: “Drivers and Utilities” CD-ROM directory structure Note The drivers and utilities used for the POC-195 panel PCs are subject to change without notice. If in doubt, check Advantech's website or contact our application engineers for the latest informa- tion regarding drivers and utilities. - Page 25 Graphic Chipset Setup This chapter describes how to install the graphics drivers. Sections include: • Introduction • Installation of Graphic Driver • Further Information...
-
Page 26: Chapter 3 Graphic Chipset Setup
Chapter 3 Graphic Chipset Setup 3.1 Introduction The POC-195 has an onboard VGA interface. The specifications and fea- tures are described as follows: 3.1.1 Chipset The POC-195 uses the Mobile Intel 915GM Express chipset for its graphic controller. It supports SDVO devices and CRT monitors. The Mobile Intel 915GM Express chipset is a component of Intel Centrino mobile technology. -
Page 27: Installation Of Graphic Driver
<Enter> means pressing the “Enter” key on the keyboard. Before you install the graphic driver of POC-195, please ensure you have installed the “Intel Chipset Software Installation Utility”. You can find this driver in the Utility CD-ROM. -
Page 28: Installation For Windows Xp
Installation for Windows XP Chipset Drivers Click 'Start', 'Run' and then select ' infinst_autol.exe' from “D:\Chipsetsoftware\” where the driver files are stored. The Install dialog will appear. Click 'Next' to continue. Read License Agreement and click 'Yes' to proceed. POC-195 User Manual... - Page 29 When the 'Setup COMPLETE' message appears click 'Finish' to restart your computer. Chapter 3...
- Page 30 Graphics Drivers Click 'Start', 'Run' and then select 'Setup.exe' from the drive direc- tory “D:\VGA\” where the driver files are stored. The Install dialog will appear. Click 'Next' to continue. Read License Agreement and click 'Yes' to proceed. POC-195 User Manual...
- Page 31 When the 'Setup COMPLETE' message appears click 'Finish' to restart your computer. Chapter 3...
-
Page 32: Further Information
3.3 Further Information For further information about the VGA installation of your POC-195, including driver updates, troubleshooting guides and FAQ lists please visit the following web resources. Intel website: www.intel.com.tw Advantech websites: www.advantech.com www.advantech.com.tw POC-195 User Manual... - Page 33 Audio Interface This chapter describes how to install the audio drivers. Sections include: • Introduction • Installation of Audio Driver • Further Information...
-
Page 34: Chapter 4 Audio Interface
Chapter 4 Audio Interface 4.1 Introduction The POC-195's onboard audio interface provides high-quality stereo sound and FM music synthesis (ESFM) by using the ALC202 audio con- troller from Realtek. The audio interface can record, compress, and play back voice, sound, and music with a built-in mixer control. The POC-... - Page 35 Click 'Next' to continue. Click 'Next' to continue. When the 'Setup COMPLETE' message appears click 'Finish' to restart your computer. Chapter 4...
-
Page 36: Further Information
4.3 Further Information For further information about the Audio interface installation in your POC-195, including driver updates, troubleshooting guides and FAQ lists please visit the following web resources. Realtek website: www.realtek.com.tw Advantech websites: www.advantech.com www.advantech.com.tw POC-195 User Manual... - Page 37 Touchscreen Interface This chapter describes how to install the touchscreen drivers. Sections include: • Introduction • Installation of Touchscreen Driver • Further Information...
-
Page 38: Chapter 5 Touchscreen Interface
5.1 Introduction 5.1.1 General Information The POC-195's optional touchscreen incorporates advanced second-gen- eration 5-wire resistive technology for 75% light transmission. The resis- tive and capacitive models have an antiglare surface. All models provide greatly enhanced visual resolution. They also have improved scratch- resistant features. -
Page 39: Installation Of Touchscreen Driver
5.2 Installation of Touchscreen Driver Follow these steps to install the touchscreen driver. Note The following windows illustrations are examples only. You must follow the flow chart instructions and pay attention to the instructions which appear on your screen. The CD-ROM drive is designated as “D” through- out this chapter. - Page 40 Click 'Unzip' to continue. Click 'Ok' to continue. POC-195 User Manual...
- Page 41 Click 'Next' to continue. Read License Agreement and click 'Yes' to proceed. Chapter 5...
- Page 42 Click 'Next' to continue. Click 'Next' to continue. POC-195 User Manual...
- Page 43 Click 'Next' to continue. Chapter 5...
- Page 44 When the 'Setup COMPLETE' message appears click 'Finish'. Fol- low the onscreen calibration procedures. POC-195 User Manual...
-
Page 45: Further Information
5.3 Further Information For further information about touchscreen in your POC-195, including driver updates, troubleshooting guides and FAQ lists please visit the fol- lowing web resources. Elo website: www.elotouch.com Advantech websites: www.advantech.com www.advantech.com.tw Chapter 5... - Page 46 POC-195 User Manual...
- Page 47 PCI Express Ethernet Interface This chapter describes how to install the Ethernet drivers. Sections include: • Introduction • Installation of Ethernet Driver • Further Information...
-
Page 48: Chapter 6 Pci Express Ethernet Interface
PCI Express Ethernet Interface 6.1 Introduction The POC-195 is equipped with the Marvell 88E8053 high performance PCIe Ethernet chipset. This chipset is fully compliant with IEEE 802.3 10/100/1000 Mbps standards. The Ethernet port is an RJ-45 jack. 6.2 Installation of Ethernet Driver 6.2.1... - Page 49 Click 'Next' to continue. When the 'Setup COMPLETE' message appears click 'Finish' to restart your computer. Chapter 6...
-
Page 50: Further Information
6.3 Further Information For further information about the Ethernet installation in your POC-195, including driver updates, troubleshooting guides and FAQ lists please visit the following web resources. Marvell website: www.marvell.com Advantech websites: www.advantech.com www.advantech.com.tw POC-195 User Manual...
