Rear View (CE5000-120AP)
AC power inlet
Power switch
Stand
Alignment shaft
Basket
CE5000-UM-251-9370
Basket
Alignment shaft
: Connects the power cord to the cutting plotter.
: Turns the power supply to the cutting plotter on or off.
: Supports the cutting-plotter unit.
: Used when loading roll media.
: Used to catch media after it has been cut.
2-4
2 PARTS NAMES and FUNCTIONS
Power switch
AC power inlet
Stand
