5 I
NSTRUMENT
Use for manual operation and monitoring the state of the instrument.
Additional controls are present when Allow calibration is selected in the Maintenance
> Advanced view. Changing calibrations can affect the performance of the instrument.
Make changes only under the direction of a Micromeritics Service Representative.
Instrument Schematic
Component
Anvil
Piston
Sample tube
MIC SAS II 5800 Operator Manual
580-42800-01 (Rev - ) — June 2019
M S
ENU ELECTION
Description
Anvil with O-ring inside sample tube. A brass plug with filter paper is
placed between the sample material and the anvil.
Piston with O-ring inside sample tube. A brass plug with filter paper is
placed between the sample material and the piston.
Steel, open-ended sample tube.

5 Instrument Menu Selection

5 - 1
