Micromeritics MIC SAS II 5800 Operator's Manual page 21

E R
DIT A ECORD
Tap the edit icon to the left of the record. Sample mass, absolute density, and text fields can be
edited. Analysis parameters are shown but cannot be changed.
Records
Field or Button
Absolute density
[text box]
Batch name [text box]
Collate results
[check box]
Mass [text box]
Material [text box]
Operator [text box]
Revert [button]
Sample name [text box]
Save [button]
MIC SAS II 5800 Operator Manual
580-42800-01 (Rev - ) — June 2019
Description
The sample density excluding the volume of pores and cavities.
Name of the analysis batch.
Produces a table in the Summary report. All analyses with the same
batch name and the Collate option enabled appear in the Summary
report.
The sample mass.
Type of sample material used for analysis.
Person running the analysis.
Returns fields to the currently saved values.
Description of the sample used for analysis.
Saves screen changes.
3 Records Menu Selection
3 - 3
