Fisher Number Map
Field or Button
Cancel [button]
Coefficients
Degree [button]
Fisher Number [column] The Fisher number from an analysis run on an instrument that uses
Include [check box]
Include origin
[check box]
Material [drop-down box] Comes from the SOPs, records, and other maps. This map will be
SAS Particle Size (μm)
[column]
Save [button]
x-axis
y-axis
MIC SAS II 5800 Operator Manual
580-42800-01 (Rev - ) — June 2019
Description
Discards any changes.
The coefficients used in the equation.
The coefficients give the n
ficients higher than the degree of the polynomial are not displayed.
Zero is shown for coefficients that are not determined because of an
insufficient number of included points. R
istic.
Fisher number.
Select to include in the fit. Errors are indicated for SAS particle sizes in
enabled rows that are not greater than zero and strictly increasing. The
graph is not updated, and
errors.
Selecting a row or focusing the Fisher number field highlights the
corresponding point in the graph. Changing the selections or the
Fisher number for a selected point updates the coefficients, R
the graph.
If selected, a point at 0, 0 is included in the line fit.
used to determine the Fisher number for all records with the selected
material.
Enter the particle size from the analysis run on the MIC SAS II.
Saves changes.
The x-axis is SAS Particle Size (μm) and the y-axis is Fisher Number.
The lower axis limits are zero; the upper limits are autoscaled. The fit is
shown as a smooth curve without points in orange. A legend identifies
the two data sets.
Fisher Number Map Report
th
order term from a polynomial fit. Coef-
2
is the usual R-squared stat-
Save is disabled when any fields have
2
, and
3 - 7
