Operating Instructions
Click on the "+/-" button to adjust delay time. Range is from 0 – 250 ms in increments
of 10ms.
Click on the or button to choose mute or unmute.

7.5.9 Audio Input Setting

Interface Introduction:
This interface allows you to set HDMI Input Audio EDID setting (2.0 CH or 5.1 CH
Audio). Default is PCM 2.0 setting.
Operating Instructions
Click on the "2.0" or "5.1" buttons separately to select the audio EDID format for the
HDMI input port.

7.5.10 Network Interface

Interface Description:
This interface is used to assign and display network information including IP/ MAC
address, Net Mask address, Gateway address and DHCP (enable/disable).
Operating Instructions
MAC Address: can only be displayed, cannot be modified.
Static IP: Default (192.168.1.168) DHCP OFF
Dynamic IP: Click the "DHCP" button to enable DHCP. The following IP address
28
