- Page 1 Mobile Projector Cart - Height Adjustable Actual product may vary from photos User Manual SKU#: ADJPROJCART For the latest information and specifications visit www.startech.com/ADJPROJCART Manual Revision: 11/27/2020...
- Page 2 This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual...
-
Page 3: Safety Statements
Säkerhetsåtgärder • Installation och/eller montering får endast göras av behöriga yrkespersoner och enligt gällande lokala förordningar för säkerhet och byggnormer. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 4: Warning Statements
• Innan du lägger till utrustning på produkten, se till att produkten är korrekt monterad, installerad och att produkten klarar av vikten på utrustningen som To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 5 • Voordat u de wagen gaat verplaatsen, moet u de zwenkwielen ontgrendelen. 注意 • 必ず取扱説明書に従って本製品の組み立てを行って下さい。 • 最初に取扱説明書を最後まで読み、 本製品の組み立て方をすべて理解して から組み立て作業を始めて下さい。 • 本製品で定められた最大積載重量を超えないようにして下さい。 最大積載 重量をオーバーした場合、 怪我をする恐れや器物破損の恐れがあります。 • TVマウンタの総耐荷重:10kg 棚ごと • 本製品に小さなお子様が乗って遊ばないようにして下さい。 お子様が使用 する際には、 適切な監視を怠らないようにして下さい。 • 本製品は、 室内での使用を想定しています。 戸外では使用しないで下さい。 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 6 • Non far passare il carrello sopra corde, cavi o superfici irregolari. • Prima di procedere allo spostamento del carrello, verificare di aver sbloccato le rotelle. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 7 • Montar este produto é uma tarefa para duas pessoas. Não tentar montar este produto e instalar o equipamento sem assistência. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 8 • No desplace el carrito encima de cables o superficies desniveladas. • Antes de empezar a mover el carrito, asegúrese de haber desbloqueado las ruedas. Antes de empezar a mover el carrito, asegúrese de haber desbloqueado las ruedas. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 9 • Bewegen Sie den Wagen nicht über Leitungen, Kabel oder unebenes Gelände. • Stellen Sie sicher, dass die Rollen entriegelt sind, bevor Sie den Wagen in Bewegung setzen. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support viii...
-
Page 10: Table Of Contents
Table of Contents Compliance Statements ................i Safety Statements ..................ii Warning Statements ................iii Product Diagram ..................1 Front Angle View ............................1 Product Dimensions ................2 Front Angle View ............................2 Product Information ................3 Package Contents ............................. 3 Technical Specifications .......................... 5 Requirements ..................5 Installation ....................6 Attach the Base ............................ -
Page 11: Product Diagram
Product Diagram Front Angle View Projector Laptop Platform Platform Knobs Support Pole Base Cross Member Base Feet Casters To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 12: Product Dimensions
Product Dimensions Front Angle View To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 13: Product Information
Washers Member Qty: 2 Qty: 2 Qty: 9 Qty: 1 Casters without Type Two Washer Nuts Casters with Brakes Brakes Qty: 1 Qty: 8 Qty: 2 Qty: 2 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 14 M6 x 30 mm M6 x 12 mm M6 x 50 mm M6 x 65mm Bolts Screws Screws Button Head Qty: 5 Screws Qty: 2 Qty: 4 Qty: 3 Mounting M6 x 50 mm Wrench Hex Key Brackets Screws Qty: 1 Qty: 1 Qty: 2 Qty: 2...
-
Page 15: Technical Specifications
Tilt Range +12° ~ -12° Requirements For the latest requirements, please visit www.startech.com/ADJPROJCART Laptop x 1 • Projector x 1 • Phillips Head Screwdriver x 1 • To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 16: Installation
Thread one Nut onto the end of the M6 x 65mm Bolt and tighten, using the Wrench. Repeat steps 2-5 for the second M6 x 65mm Bolt. Repeat steps 2-6 for the second Base Foot. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 17: Attach The Casters
Base Feet and tighten, using the Wrench. Flip the Base upright so that the Casters are making contact with the surface. Note: For uneven surfaces, adjust the position of the Nut on each Caster. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 18: Attach The Support Pole
Support Pole and into the Base Cross Member. Tighten all four M6 x 12 mm Screws, using the Hex Key. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 19: Attach The Laptop Platform
Place the Laptop Platform onto the ledge located on the side of the Support Pole. Align the holes in the top of the Laptop Platform and the Support Pole. (Figure 5) To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 20: Attach The Knobs
Repeat steps 2-4 for the second M6 x 30 mm Screw. Attach the Knobs Inner Portion of Support Pole M6 x 50 mm Button Knobs Head Screws Figure 6 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 21: Attach The Mounting Brackets
Determine the desired height setting for the Projector Platform. The Projector Platform can be adjusted from 37.4” (950 mm) to 57” (1450 mm) in pre-set increments. Extend the inner portion of the Support Pole to the desired height setting. Insert two M6 x 50 mm Button Head Screws through the two holes located in the outer portion of the Support Pole. -
Page 22: Attach The Projector Platform
Thread one Nut onto the M6 x 50 mm Screw and tighten by holding the Nut with the Wrench and by tightening the M6 x 50 mm Screw, using the Hex Key. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 23: Operation
Projector Cart. Determine the desired height setting for the Projector Platform. The Projector Platform can be adjusted from 37.4” (950 mm) to 57” (1450 mm) in pre-set increments. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 24: Tilt The Projector Platform
Loosen and remove the Knob on each one of the M6 x 50 mm Button Head Screws. Remove the two M6 x 50 mm Button Head Screws from the two holes located in the outer portion of the Support Pole. Adjust the inner portion of the Support Pole to the desired height setting. - Page 25 Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.
