Sliding Gate Opener
User's Manual
Model:
CK500
TOPENS Website
http://www.topenstool.com/
★ Please read and follow all warnings, precautions and instructions before
installation and use.
★ Periodic checks of the opener are required to ensure safe operation.
★ Save this manual.
C030510
VER 20a

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CK500 and is the answer not in the manual?

Questions and answers

Summary of Contents for Topens CK500

  • Page 1 Sliding Gate Opener User’s Manual Model: CK500 TOPENS Website http://www.topenstool.com/ ★ Please read and follow all warnings, precautions and instructions before installation and use. ★ Periodic checks of the opener are required to ensure safe operation. ★ Save this manual.
  • Page 2: Table Of Contents

    Preparation for Installation ..........................2 Parts List ................................3 Accessories Parts (Included in some models, refers to the actual package) ..........4 Optional Accessories Parts List (Available at TOPENS Store) ................ 4 Technical Specifications & Features ........................ 4 Installation Overview ............................5 Installation of the Opener ..........................
  • Page 3: General Safety

    Thank you for purchasing our sliding gate opener. We are sure that the products will be greatly satisfying as soon as you start to use it. The product is supplied with a user’s manual which encloses installation and safety precautions. These should be read carefully before installation and operation as they provide important information about safety, installation, operation and maintenance.
  • Page 4: Preparation For Installation

    • Do not allow persons or children to remain in the automation operation area. • Keep radio control or other control devices out of children’s reach, in order to avoid unintentional automation activation. • The user must avoid any attempt to carry out work or repair on the automation system, and always request the assistance of qualified personnel.
  • Page 5: Parts List

    Parts List...
  • Page 6: Accessories Parts (Included In Some Models, Refers To The Actual Package)

    Accessories Parts (Included in some models, refers to the actual package) Optional Accessories Parts List (Available at TOPENS Store) Technical Specifications & Features Specifications CK500 Power input: 110~120V/60Hz or 220~240V/50Hz Motor voltage: 120VAC or 230VAC Rated power: 300W Gate moving speed: 21 cm/s (8.3 in/s)
  • Page 7: Installation Overview

    ·Built in max. Motor Running Time (MRT) for multiple Features: safety protection (90 seconds) ·Midway mode. ·Reliable electromagnetism limit for easy adjustment ·Quick selection for the gate open/close direction ·Can be equipped with a wide range accessories ·Reliable rolling code technology for remote control ·Easy install, minimum...
  • Page 8 2). Make sure there is 1” distance at least between the wheel cover and the gate after you position the base plate. Caution: *Be sure that the opener is installed in a level and paralleled position. Improper installation could result in property damage, severe injury, and/or death.
  • Page 9: Manual Operation

    Manual Operation You can open the gate by manual when power failure. And the opener should be put in the manual (emergency release) position before fitting the rack, installing the opener and limit switch. The process is as follows: Insert the Release Key and turn it in clockwise 90°, then pull the release handle in clockwise 90° to disengage the clutch between the gear shaft and motor.
  • Page 10: Installation Of The Magnets

    Installation of the Magnets Before install limit switch, make sure the gate opener is put in manual operation. (the clutch connected with gear shaft is disengaged) and the mains power supply is disconnected. Position the two Magnet Components approximately on the gate and move the gate by hand to fix them in place. Fit magnets bracket Push the gate fully closed by hand.
  • Page 11 Connecting of the Control Board 1. Motor The BLACK wire of the motor should be connected into the “3” terminal. The YELLOW wire of the motor should be connected into the “4” terminal. The RED wire of the motor should be connected into the “5” terminal. 2.
  • Page 12: Setting Of The Control Board

    4. Start Capacitor The two wires of the start capacitor should be connected into the “4”terminal and “5” terminal. 5. Photocell Beam System (PBS) (Included in some models, refers to the actual package) Use a 2-core cable to connect the “+ ~” terminal of the photocell’s emitter to the “11” terminal, the “- ~” terminal to the “13”...
  • Page 13 would be disabled if both DIP switches are turned off. Factory default setting is disabled. The midway mode could be activated by pressing button B of the remote control when the gate is in the full closed position. E.g. Running time of the operator in midway mode is 2 seconds. DIP Switch #3: Auto close function enabled/disabled DIP Switch #3: ON –...
  • Page 14: Test The Reversing Sensitivity

    Press and hold the learn button until the LEARN light is off. Now all remote codes have been erased.  Max. 8 remotes can be programmed for the opener. An External Receiver (optional) allows up to 250pcs remotes to be programmed for the opener. TOPENS ERM12 Universal External Receiver is available at TOPENS Store.
  • Page 15: How To Use The Remote To Operate Your Gate Opener

    All of TOPENS sliding gate opener have midway mode. Button B is designed to realize midway function (refer to more details in our TOPENS sliding gate opener manual). So it is must program button A with sliding gate opener, while you may program either C button or D button with TOPENS swing gate opener.
  • Page 16 Troubleshooting Have a multimeter to check voltage and continuity. Use caution when checking high voltage terminals. Symptom Possible Solution(s) 1. Check the input voltage of the control board. It should be local AC electricity. 2. Check the fuse in the control board. Replace the fuse if it was burnt out. 3.
  • Page 17 then use a jumper wire to short the 3 terminals together to try it again. Replace the limit switch if the motor could run in both directions. 3. Check the control board. Replace the control board if necessary. The gate will open Ensure the DIP 4# has been set correctly according to the installation for automatically instead “Left Open”...
  • Page 18 TOPENS Website http://www.topenstool.com/ Any question, please do not hesitate to contact us: E-mail: support@topenstool.com Kindly include your Product Model, Purchasing Date & Site, Order #, and your contact information. All your concerns will be replied within 24 hours. Tel: +86 (571) 8908 0213 (China)
