Sliding Gate Opener
User's Manual
Model:
CK1100
TOPENS Website
www.topens.com
Email: support@topens.com
★ Please read and follow all warnings, precautions and instructions before
installation and use.
★ Periodic checks of the opener are required to ensure safe operation.
★ Save this manual.
C030614
VER 22a
Advertisement
Table of Contents
Related Manuals for Topens CK1100
Summary of Contents for Topens CK1100
- Page 1 Sliding Gate Opener User’s Manual Model: CK1100 TOPENS Website www.topens.com Email: support@topens.com ★ Please read and follow all warnings, precautions and instructions before installation and use. ★ Periodic checks of the opener are required to ensure safe operation. ★ Save this manual.
- Page 2 Visit: www.topens.com Please record the product model, your email address etc. in the spaces provided below. Refer to this list when contacting TOPENS for technical service or assistance with your automatic gate opener. Where did you purchase? (Amazon.com; Amazon.ca: Amazon.co.uk, Amazon.de; Other, Please...
-
Page 3: Table Of Contents
General Safety.................................. 1 Preparation for Installation..............................2 Parts List.................................... 4 Accessories Parts (Included in some models, refers to the actual package)............4 Optional Accessories Parts List (Available at TOPENS Store)................5 Replacement Parts................................5 Technical Specifications & Features..........................6 Installation Overview................................6 Installation of the Opener..............................7 Manual Operation................................7... -
Page 4: Check Your Gate Before Installation
Thank you for purchasing our sliding gate opener. We are sure that the products will be greatly satisfying as soon as you start to use it. The product is supplied with a user’s manual which encloses installation and safety precautions. These should be read carefully before installation and operation as they provide important information about safety, installation, operation and maintenance. -
Page 5: Preparation For Installation
• Position at least one visible indication device, and fix a Warning sign to the structure. • The factory declines all responsibility with respect to the automation safety and correct operation when other supplier’s components are used. • Only use original parts for any maintenance or repair operation. •... - Page 6 In sake of safety, a positive stop must be mounted on the two end of ground track.
-
Page 7: Parts List
Parts List Accessories Parts (Included in some models, refers to the actual package) -
Page 8: Optional Accessories Parts List (Available At Topens Store)
LT08B 20 Feet Roller Sensor AC Warning Light Chain Replacement Parts ACPYMJ7A Control ACPYMJ8A Control PYMJ-CKG Limit Switch Board (120V) Board (230V) WARNING: Changes or modifications not expressly specified by this user manual, TOPENS could void the warranty of this equipment. -
Page 9: Technical Specifications & Features
Technical Specifications & Features Specifications CK1100 Power input: 110~120V/60Hz or 220~240V/50Hz Motor voltage: 120VAC or 230VAC Rated power: 450W Gate moving speed: 20 cm/s (8 in/s) Max gate weight: 1300kg (2800lbs) Environmental conditions: -20℃~ +50℃ (0°F to 120°F) Protection class: IP44 ·Built in max. -
Page 10: Installation Of The Opener
Installation of the Opener Caution: *Be sure that the opener is installed in a level and paralleled position. Improper installation could result in property damage, severe injury, and/or death. * Before starting installation, ensure that there is no point of friction during the entire movement of the gate and there is no danger of derailment. -
Page 11: Installation Of Chain And Chain Brackets
Installation of chain and chain brackets 1. Chain Brackets 1). Please refer to below chain brackets figure, which shows “U” bolt, “L” bracket and chain bolt. Use the “U” bolts (square or round) to attach the chain brackets to gate frame. 2). -
Page 12: Installation Of The Magnets
7). Make sure there is 1” distance at least between the wheel cover and the gate after you position the base plate. Installation of the Magnets Before install limit switch, make sure the gate opener is put in manual operation. (the clutch connected with gear shaft is disengaged) and the mains power supply is disconnected. -
Page 13: Connecting Of Power Supply
Connecting of Power Supply WARNING: NEVER connect the gate opener to the power outlet before all the installations have been done. The power supply cord should be at least 3×0.75mm (3C×18AWG). Connect the live wire and neutral wire to the “L” (2) and “N” (1) terminal of the control board respectively;... -
Page 14: Setting Of The Control Board
The BLACK wire of the motor should be connected into the “3” terminal. The YELLOW wire of the motor should be connected into the “4” terminal. The RED wire of the motor should be connected into the “5” terminal. 2. Limit Switches The YELLOW wire of the limit switches should be connected into the “8”... - Page 15 1. DIP Switches The DIP switches are used to set the running time of the motor in pedestrian mode, enable/disable auto close function of the gate operator and fast change the open/close direction which is determined by the position of the gate operator installed. DIP Switch #1–#2: Running time of the motor in Midway Mode DIP Switch #1: ON –...
-
Page 16: Test The Reversing Sensitivity
stall force. WARNING: Photocell is highly recommended to be installed with the gate opener as entrapment protection for safety when you set stall force to maximum. Turn potentiometer B clockwise to increase the auto close time, and turn it counter-clockwise to decrease the auto close time, the auto close time could be adjusted gradually from 1 to 99 seconds. -
Page 17: How To Use The Remote To Operate Your Gate Opener
All of TOPENS sliding gate opener have midway mode. Button B is designed to realize midway function (refer to more details in our TOPENS sliding gate opener manual). So it is must program button A with sliding gate opener, while you may program either C button or D button with TOPENS swing gate opener. - Page 18 NOTE: Every step for pressing button during program must be finished within 1 second to ensure successful programming. Troubleshooting Have a multimeter to check voltage and continuity. Use caution when checking high voltage terminals. Symptom Possible Solution(s) 1. Check the input voltage of the control board. It should be local AC electricity.
-
Page 19: Maintenance
return. Check the limit switch. Remove the wire connection of the limit switch which is connected to the 8#, 9#, and 10# terminals of the control board and then use a jumper wire to short the 3 terminals together to try it again. Replace the limit switch if the motor could run in both directions. - Page 20 Your comments and suggestions are important to us as they help us provide the best possible service. Should you have any need to contact us, the info below will help you get in touch: TOPENS Website www.topens.com Contact Us: E-mail: support@topens.com Kindly include your Product Model, Purchasing Date &...
