Topens AT1202 User Manual

Dual swing gate opener
Hide thumbs
Table of Contents

Advertisement

Quick Links

Dual Swing Gate Opener
User's Manual
Model:
AT1202
TOPENS Website
http://www.topenstool.com/
★ Please read and follow all warnings, precautions and instructions before
installation and use.
★ Never connect the solar panel to the control board directly to charge the battery.
★ Periodic checks of the opener are required to ensure safe operation.
★ Save this manual.
VER 20b
C030495

Advertisement

Table of Contents
loading

Related Manuals for Topens AT1202

Summary of Contents for Topens AT1202

  • Page 1 Dual Swing Gate Opener User’s Manual Model: AT1202 TOPENS Website http://www.topenstool.com/ ★ Please read and follow all warnings, precautions and instructions before installation and use. ★ Never connect the solar panel to the control board directly to charge the battery.

  • Page 2: Table Of Contents

    Safety Installation Information ........................1 AT1202 Parts List ............................2 Accessories Parts (Included in some models, refers to the actual package) ............3 Optional Accessories Parts List (Available at TOPENS Store) ................3 Tools Needed: ............................... 3 Technical Specifications & Features ......................4 Installation Overview .............................

  • Page 3: Safety Installation Information

    use on any pedestrian gate. Pedestrians must be Safety Installation Information supplied with a separate pedestrian access. 1. READ and FOLLOW all instruction. For an installation utilizing non-contact sensors The gate opener is intended for use with Class I (safety sensors), see product manual on the vehicular swing gates.

  • Page 4: At1202 Parts List

    13. To AVOID damaging gas, power, or other SAVE INSTRUCTION. underground utility lines, contact underground utility 14. Do not permit children to play on or around the locating companies BEFORE digging. gate and keep all controls out of their reach. AT1202 Parts List...

  • Page 5: Accessories Parts (Included In Some Models, Refers To The Actual Package)

    Accessories Parts (Included in some models, refers to the actual package) Optional Accessories Parts List (Available at TOPENS Store) Tools Needed: ·Power Drill ·Tape Measure ·Open End Wrenches — 14# &17# or Adjustable Wrenches ·Wire Strippers ·C-Clamps — small, medium, and large ·Level...

  • Page 6: Technical Specifications & Features

    Technical Specifications & Features Specifications Model: AT1202 Input: 110V~120V/60Hz or 220~240V/50Hz Motor voltage: 24VDC Power: 2×80W Current: Actuator speed: 16mm/s（0.6 in/s） Max. actuator travel: 385mm（15.2 in） -20℃~ +50℃ (-4°F to 122°F) Ambient Temperature: Protection class: IP44 Features: ·Soft start and soft stop ·Emergency release key in case of power failure...

  • Page 7: Installation Overview

    Installation Overview Pull-to-Open Gates Important: The second gate opener cable should be put into the PVC conduit (not provided) which is buried underground .This protects the cable from lawn mowers and string trimmers. Rev 20a...

  • Page 8: Preparation For Installation

    Preparation for Installation There are two installation types for the gate opener, Pull-to-Open and Push-to-Open. In the Push-to-Open installation, gate opens out from the property. A Push-To-Open Bracket (PSO part) is required to be used for each gate. NOTE: Ensure the gate does not open into public areas. The gate opener is mounted to the gate and to the gate post.
  • Page 9 Push-to-Open Installation — Gate in Closed position (Moving-Rod is retracted) 1. Insert the M10 x 30 bolt through the center hole of the post bracket and post pivot bracket as shown. Place a ￠10 washer , ￠10 lock washer and M10 nut on the bottom of the bolt and hand tighten. 2.
  • Page 10 5. Make sure that there is a minimum clearance of 2.5cm between the gate and the opener and that the opener and the Post Pivot Bracket are not binding in both the gate-open and gate-closed positions. If there is not at least 2.5cm of clearance or if the opener and the Post Pivot Bracket are binding, rotate the Post Pivot Bracket and/or move the Post Bracket Assembly to obtain the minimum clearance and eliminate the binding.
  • Page 11 6. Sign the bolt-hole point on the gate bracket and gate. Do this by placing a punch or a sign in the middle of each bolt slot on the post bracket assemblies and the gate bracket. It allows slight adjustments to the post bracket.

  • Page 12: Mounting The Control Box

    12. Open the release hole plug on the top of the gate opener, insert the release key, and turn the key 90° counterclockwise. This restores normal operation. Mounting the Control Box Step 1 To install the control box use the deck screws (not provided). Even though the control box is waterproof designed, for safety reason and a longer service life, it is recommended to install the control box inside a secure surface and at least 100 cm (40 inches) above the...

  • Page 13: Connection Of The Power Supply

    Step 3 Insert the cable of the motor2 and alarm lamp cables into the control box through middle strain relief. Then repeat step 2. Step 4 Insert other cables into the control box through rightmost strain relief. Then repeat step 2. CAUTION: Make sure the cable outlet hole in the Control Box is always down during installation so as to drain off the water.

  • Page 14: Connecting Of The Control Board

    Connecting of the Control Board...
  • Page 15 Motor connection for PUSH-TO-OPEN The motors’ power wires and limit wires connection by “Push to Open” is different from the connection by “Pull to Open”. So motor 1 and motor 2 wires should be connected to the control box as the instruction on the right. The black wire should be inserted into the Motor+ terminal, the red wire should be inserted into the Motor- terminal, the yellow wire into ULT1 terminal, the blue wire into DLT1...

  • Page 16: How To Program Or Erase The Remote

    Please note that the adapter board of the exit wand should be inserted into the main control board of the gate opener before using. The BLACK and the BLUE wire of the exit wand should be connected into the “LOOP” terminal, no matter the polarity.

  • Page 17: How To Use The Remote To Operate Your Gate Opener

    All of TOPENS sliding gate opener have midway mode. Button B is designed to realize midway function (refer to more details in our TOPENS sliding gate opener manual). So it is must program button A with sliding gate opener, while you may program either C button or D button with TOPENS swing gate opener.

  • Page 18: Setting Of The Control Board

    NOTE: Every step for pressing button during program must be finished within 1 second to ensure successful programming. Setting of the Control Board WARNING: Ensure the gate opener is Power Off when you make any adjustment of the gate opener. Keep away from the path of the gate during you set the gate opener system in case of the unexpected gate moving.
  • Page 19 close interval is 9 seconds. Each time you press and release the “INC” button, the figure increases by 1, and the Slave gate starts to close 1 more second earlier. Each time you press and release the “DEC” button, the figure decreases by 1, and the interval decreases by 1 second.
  • Page 20 7-b. Adjust the MRT of MOTOR2 When the Digital Display indicates “P8”, you can adjust the MRT of MOTOR2. Please perform the same procedure as adjusting MOTOR1 (7-a). Press the “FUNC” button to store the data when you finish setting. The Digital Display will indicate “P9”. Now MOTOR2 adjustment is finished.

  • Page 21: Indicate Illustration On The Digital Display When Gate Opener Is Running

    and the opener enters standby mode. Indicate Illustration on the Digital Display When Gate Opener is Running The left image on Digital Display symbolizes motor of gate opener when the gate opener is running. The right image on Digital Display symbolizes motor of gate opener When the motor is run to gate -open direction or gate -close direction, the image on Digital Display indicates “n”...

  • Page 22: Trouble Shooting

    NOTES: 1. Inspection and service should always be performed anytime a malfunction is observed or suspected. 2. It is suggested that while at the site voltage readings be taken at the operator. Using a Digital Voltmeter, verify that the incoming voltage to the opener it is within ten percent of the opener’s rating. 3.

  • Page 23: Quick-Setting Guide

    Quick-Setting Guide...
  • Page 27 TOPENS Website http://www.topenstool.com/ Any question, please do not hesitate to contact us: E-mail: support@topenstool.com Kindly include your Product Model, Purchasing Date & Site, Order #, and your contact information. All your concerns will be replied within 24 hours. Tel: +86 (571) 8908 0213 (China)
