FIGURE 2–34.
Use normal tool insertion
Enable/Disable the mask
Draw filled rectangles
Draw unfilled rectangles
• Fill ROI — Fills the entire ROI of the masked tool.
• Clear ROI — Erases the entire ROI of the masked tool.
v4.1.3, April 2012
ROI Masking Toolbar Descriptions
4x4 square pen
2x2 square pen
1x1 square pen
16x16 square pen
14x14 square pen
12x12 square pen
Erase Mask instead
of Draw Mask
Fill connected areas
Visionscape FrontRunner™ User's Manual
Miscellaneous
10x10 square pen
8x8 square pen
6x6 square pen
Draw solid lines
Draw free-style with a brush
Draw filled circles
Draw unfilled circles
