CHAPTER 4
Every Inspection step maintains a queue of the last n cycle images and
results. You decide how large the queue will be and what gets stored in it:
• Results and images for every part
• Results and images for passed parts
• Results and images for failed parts
If you activate the Queue, the Part Queue Viewer allows you to upload it,
and view any of the images and results that were stored on the device at
runtime.
Note: The Part Queue allows you to review runtime images only.
The remainder of this chapter contains information about:
• "Setting Up and Starting the Part Queue" on page 4-2
• "Viewing Images in the Part Queue" on page 4-7
• "Saving Images and Records" on page 4-8
v4.1.3, April 2012
The Part Queue
Visionscape FrontRunner™ User's Manual
4
4-1
