APPENDIX A
To successfully use Visionscape
precise image of the part and features you want to inspect. Using the VS-
1 Smart Camera as an example, the following factors contribute to
obtaining a good image include:
• "Determining Field Of View (FOV)" on page A-1
• "Selecting a Lens" on page A-2
• "Illuminating the Part" on page A-4
• "Advanced Lighting" on page A-11
• "Aperture" on page A-15
• "Depth of Field" on page A-16
• "Lighting Tips" on page A-16
Determining Field Of View (FOV)
Determining the best field of view, that is the area viewed by the camera
is your first consideration before setting up a camera for your application.
The object of interest should appear as large as possible in the field of
view. The field of view should clearly show the level of detail you want to
see while ensuring that the part to be inspected is always seen by the
camera.
