without displaying the Save Job dialog box. If you want to save the
current Job with a different name, select File > Save Job As. In the
File name text box, type a different name for the Job you want to
save, and then click Save.
Note: If the current Job changes through editing, the Save button is
red.
• Save Program on Device to Flash Memory — Saves the current Job
on the camera to Non-Volatile memory. You can only flash the Smart
Camera when it is stopped. This operation takes some time.
Note: Do not perform Save Program on Device to Flash Memory
often (as a replacement for Job change over, for example).
• Upload Program from Device to PC — Uploads the current Job on the
camera to the PC.
• Download Program from PC to Device — Downloads the current Job
from the PC to the camera.
• Start Program on Device / Stop Program on Device — Use these
buttons to start and stop the current Job.
• Train Selected Step — Some tools (like the Barcode Tool and the
Data Matrix Tool) can be trained. When you train a tool, you are
"telling" the tool what to expect when it reads an image. For example,
if you train the Data Matrix tool to read a Data Matrix with 12 rows and
12 columns, the Data Matrix tool will fail when it encounters a Data
Matrix with 16 rows and 16 columns. You will know a tool needs to be
trained when you see:
–
–
• Untrain Selected Step — Just as some tools (Barcode and Data
Matrix) need to be trained, those same tools may need to be
untrained when you want them to read a part that differs from the part
they have been reading. For example, if you train a Data Matrix tool to
read a Data Matrix with 8 rows and 32 columns, it will not read a Data
v4.1.3, April 2012
A red x to the left of the tool name
The red Train button
