3.20.4.3 Corridor width > Guide
The guide corridor width is adjusted automatically. Only
in rare occasions manual settings need to be entered.
The guide corridor width can be set between
If guide corridor width is set to
will straddle the guide wire. This means that the robotic
lawnmower runs right over the guide wire.
Use the arrow keys to specify the required value.
9 .
The factory setting is
3.20.4.4 Exit angles
Normally the robotic lawnmower leaves the charging
station in a direction within the 90°-270° exit sector. By
changing the exit angles, it makes it easier for the
robotic lawnmower to reach the working areas.
3.20.4.5 Exit angles > Sectors
The robotic lawnmower can be set for 1 or 2 exit
sectors. If the charging station is placed in a passage, 2
exit angles, for instance 70° - 110° and 250° - 290°, can
be used.
When 2 exit angles are used, there is a need to also
specify how often the robotic lawnmower must leave the
Sector 1 . This is done using the
charging station in
Proportion function by initially specifying a percentage.
For instance the percentage of 75 % means that the
robotic lawnmower leaves the charging station in
1 on 75% of the times and 25% of the times in Sector 2 .
Use the number keys to specify the required angles in
degrees for the sectors and proportion as a percentage.
3.20.4.6 Reversing distance
This functions allows you to control how far the robotic
lawnmower reverses out from the charging station
before it starts mowing. This is a useful function for
instance if the charging station is placed way in under a
veranda or in another limited space area.
Use the number keys to specify the required reverse
distance in centimetres. The factory setting is 60 cm.
32 - Installation
0 and 9 .
0 , the robotic lawnmower
Sector
3.20.4.7 Drive past wire
The front of the robotic lawnmower always passes the
boundary wire by a specific distance before the mower
turns around. The default distance is 32 cm, but this can
be changed if required. A figure between 25 and 50 can
be selected.
Note that the distance given is only an approximate
value and should be regarded as a guide. In reality, the
actual distance the robotic mower passes the boundary
wire can vary.
Specify the number of centimetres you want the robotic
lawnmower to pass the boundary wire and press OK.

3.21 Settings

This selection allows you to carry out changes to the
robotic lawnmower's general settings.
SETTINGS
Profiles
ECO mode
Spiral cutting
General
3.21.1 Profiles
Only applicable to Automower
315X.
Profiles , different sets of user settings
With the function
can be saved. Up to 3 different profiles can be stored.
The unique connection between the mower and the
charging station is saved in the profiles. This means that
the settings can be easily stored and reused if the
robotic lawnmower for example will be used in different
gardens. This enables up to 3 charging stations to be
connected to the same robotic lawnmower.
® ®
315 and Automower
