STM3210C-EVAL I/O assignment

Table 27. STM3210C-EVAL I/O assignment

Pin No. Pin name
1 PE2
2 PE3
3 PE4
4 PE5
5 PE6
6 VBAT
7 PC13-ANTI_TAMP
8 PC14-OSC32_IN
9 PC15-OSC32_OUT 32K OSC
10 VSS_5
11 VDD_5
12 OSC_IN
13 OSC_OUT
14 NRST
15 PC0
16 PC1
17 PC2
18 PC3
19 VSSA
20 VREF-
21 VREF+
22 VDDA
23 PA0-WKUP
24 PA1
25 PA2
26 PA3
27 VSS_4
28 VDD_4
29 PA4
30 PA5
31 PA6
32 PA7
STM3210C-EVAL I/O assignment
Trace_CK
Trace_D0
Trace_D1
Trace_D2
Trace_D3
Battery
Anti-tamper button / IDD_CNT_EN
32K OSC
GND
+3V3
25MHz OSC
25MHz OSC
RESET#
MC_ADC10 pin 26 (heatsinktemp) / SmartCard_3/5V
ETHER_MDC
ETHER_TXD2
ETHER_TX_CLK
GND
GND
+3V3
+3V3
ETHER_CRS / IDD_WAKEUP / MC_TIM5_CH1 pin 23
(Dissip_brake)
ETHER_RX_CLK
ETHER_MDIO
ETHER_COL
GND
+3V3
MicroSD card CS / Audio_DAC
MC_ADC5 pin 14 (Bus voltage)
IDD_Measure
MC_ADC7 pin 15 (Current A)/BNC1
