Display Bezel; Removing The Display Bezel - Dell Precision 3560 Service Manual

Next steps
1. Install the WWAN card.
2. Install the WLAN card.
3. Install the base cover.
4. Install the microSD card.
5. Install the SIM card.
6. Follow the procedure in

Display bezel

Removing the display bezel

Prerequisites
1. Follow the procedure in
2. Remove the SIM card.
3. Remove the microSD
4. Remove the base cover.
5. Remove the display assembly.
About this task
The following images indicate the location of the display bezel and provide a visual representation of the removal procedure.
Steps
NOTE: The display bezel is adhered to the display panel with adhesive. Insert a plastic scribe into the recesses near both
hinge caps to start the prying process to release the display bezel. Pry along the outside edge of the display bezel and work
your way around the entire display bezel until the display bezel is separated from the display cover.
CAUTION: Carefully pry and remove the display bezel to minimize the risk of display panel damages.
70 Removing and installing components
After working inside your
Before working inside your
card.
computer.
computer.
