- Page 1 Description and Operating Instructions VENTIsupport Version 1 Compliance and titration software...
-
Page 2: Table Of Contents
4. Operation ......9 4.1 Starting VENTIsupport ....9 4.2 Selecting the language . - Page 3 5 Connection C for connection line 6 4 Connection B for 1 CD ROM with software connection line VENTIsupport 6 Connection cable 2 Converter box converter box/ 3 Connection A for connection line 7 7 Connection cable converter 9 Control line (for...
-
Page 4: Description
1. Description 1.1 Purpose VENTIsupport is the PC software designed to accom- pany Weinmann therapy devices. It makes it possible to read and display therapy control data, and also permits PC-aided analysis. With its VENTIadjust re- mote settings module, VENTIsupport also allows you to display and set therapy parameters. -
Page 5: Safety
For your own safety please observe the following points: • Read these operating instructions carefully. They are part of VENTIsupport and must be kept available at all times. • Use VENTIsupport for the designated purpose on- ly. Only therapy devices manufactured by Wein- mann may be connected to the converter box. - Page 6 Protect the CD ROM from intense sunshine or me- chanical effects such as bending and scratching. • Observe the online help provided as part of the VENTIsupport software. It is part of VENTIsupport. • Please ensure that selection of adjustment of the therapy parameters using VENTIsupport (VENTIadjust functionality) does not simultaneously bring about changes to the therapy device.
- Page 7 System Standard VDE 0750 Part 1- 1 is observed. If you have additional questions, please contact your local distributor or the custom- er service department of Weinmann. • Malfunctions may result if third-party articles are used. Please bear in mind that in these cases any...
-
Page 8: Installation
3. Installation 3.1 System requirements The VENTIsupport software requires an IBM compati- ble computer that satisfies the following requirements: Processor: Pentium III, 1 GHz or better Free storage: at least 300 MB on a hard drive, at least 50 MB in system partition... -
Page 9: Software Installation
3.2 Software installation Note: VENTIsupport is not designed for installation on network drives. Install VENTIsupport on a local hard disk. Our hot- line is available to help with questions and problems of all kinds: Phone: +49/40/5 47 02-0 E-mail: ventisupport.hotline@weinmann.de 1. -
Page 10: Deinstallation
If you would not like any other user except for you to use the VENTIsupport Software, click on Only for me 2. The installation program will suggest installing the VENTIsupport software in the directory: C:\Program Files\Weinmann\VENTIsupport If you accept this path, click on the button. -
Page 11: Operation
Online Help, turn to the chapter “4.3 On- line Help” on page 10. 4.1 Starting VENTIsupport 1. If the VENTIsupport icon is located directly on your graphical user interface, (because you placed a link on your desktop), you can open the program by double-clicking on the icon. -
Page 12: Online Help
2. Click on the Print icon. – Select from the Print the selected topic Print Top- menu and click 3. Click in the print dialog to start printing. Printing the entire Online Help The Online Help covers the functionality of both VENTIsupport and VENTIadjust. -
Page 13: Connecting Therapy Devices To The Pc
You can print the Online Help for VENTIsupport and VENTIadjust as follows: 1. On the tab, mark the folder VENTIsupport Contents or VENTIadjust. 2. Click on the Print icon. 3. Select Print the selected heading and all subtopics from the... - Page 14 Adjusting the COM connection If you have not connected the therapy device onto the COM2 connection of your computer, adjust the COM connection as follows: 1. Please start VENTIsupport (see "4.1 Starting VENTIsupport" on page 9). 2. Select the submenu in the menu.
-
Page 15: Remote Settings For The Therapy Device
4.5 Remote settings for the therapy device 1. Make certain that the therapy device is receiving electrical power. 2. Please start the VENTIsupport Software (see "4.1 Starting VENTIsupport" on page 9). 3. Start the remote settings with the menu item... -
Page 16: Functional Check
5. Functional check The installer copies a demo file to the subdirectory . You can use this file to test the options of the \Data VENTIsupport software: 1. Start VENTIsupport. 2. Select from the menu. Open File 3. Select the subdirectory Data 4. -
Page 17: Maintenance
The data in the therapy device was inad- The therapy device does Error cannot be corrected. Record vertently deleted despite a warning mes- not contain any data. the data again. sage from the VENTIsupport software. -
Page 18: Scope Of Supply
8.1 Standard product VENTIsupport WM 93340 consisting of: Item Order No. Software VENTIsupport (1 CD-ROM 1) WM 93350 Converter box 2 WM 93316 Connection line 6 Converter box/PC, 2 m WM 93312 Connection line 7 Converter box/therapy device, 2 m WM 93313... -
Page 19: Technical Data
HF device in W 150 KHz - 80 MHz 80 MHz – 800 MHz 800 MHz – 2.5 GHz 0.01 0.12 0.12 0.24 0.37 0.37 0.74 1.17 1.17 2.34 3.69 3.69 7.38 11.67 11.67 23.33 Contact Weinmann for further technical specifications. -
Page 20: Warranty
Weinmann reserves the right to decide whether to elim- inate defects, to deliver a defect-free item or to reduce the purchase price by a reasonable amount. • If Weinmann rejects a claim against the warranty, it as- sumes no expense for transport between customer and manufacturer. •... - Page 22 For decades Weinmann has been developing, producing and marketing medical devices for markets around the world. In cooperation with our partners we design economic health systems for diagnosis and therapy in Sleep Medicine, Home Mechanical Ventilation, Oxygen Medicine and Emergency Medicine.
