1 Introduction

Thanks for choosing our product.
The ROCK family is a new generation of autonomous vibration monitoring device for vibration
compliance to widely used standards worldwide. It integrates highly innovative and proven technologies
for ultra-low power and most advanced 4G LTE communication with embedded SIM card.
The ROCK is operable with the Syscom Cloud Software (SCS), granting unrivalled ease for remote
monitoring due to its automation.
SYSCOM is now able to offer the perfect combination of hardware and software, with cable free, extra-
large autonomy field monitoring ROCK stations and state of the art data processing software SCS.
As a prime service offering, versatile device parametrization and high end features complete this
monitoring solution. For outdoor usage, a ROCK SOLAR with an embedded solar panel extends the
autonomy of the system.
Syscom believe in open architecture systems and data sharing is therefore a core feature of this
monitoring solution. Capabilities such as FTP data transfer, ASCII file export and URL link sharing can
be done in 1-click.
Typical non exhaustive applications are construction site monitoring, tunnel monitoring, piling
monitoring, blasting monitoring and structural monitoring.
Please refer to this user manual for any questions related to the ROCK device and related functionalities
in the SCS.
Tutorial videos are available on the Syscom website:
cloud-software/tutorial-videos/

1.1 Features

The ROCK device includes the following major features:
Compact aluminum unit containing triaxial velocity sensor, digital recorder, 4G communication
o
and battery
Extended autonomy due to its ultra-low power design, cable free installation suitability
o
Embedded memory for data safety
o
Wide dynamic range 110dB@1000sps
o
Sampling rate up to 4000 Hz
o
Internal 96Wh UN38.3 certified lithium battery
o
Fully managed by Syscom Cloud Software (SCS)
o
Compliance to worldwide standard (refer to list in §1.3)
o
Suitable for permanent monitoring
o
Lowest cost of ownership
o
Embedded solar panel in option
o
Refer to ROCK datasheet for complete technical specifications.
