- Page 1 User Manual MR3000DMS Firmware Version 2.0.x © SYSCOM Instruments SA Rue de l'Industrie 21 1450 Sainte-Croix Switzerland Tel +41 24 455 44 11 Fax +41 24 454 45 60 sales@bartec-syscom.com www.bartec-syscom.com...
-
Page 2: Table Of Contents
3.1 Connecting to the DMS for the first time (direct connection)......24 3.1.1. Wired connection via router..................24 3.1.2. Wired connection without switch/router..............25 3.2 Connecting to the MR3000DMS in the field (remote connection)......26 4. OPERATING WITH THE MR3000DMS............28 4.1 Preparing the DMS for field use................28 4.1.1. - Page 3 - 3 - 4.1.3. Alerts........................32 4.1.4. Measurements settings..................33 4.1.5. Site installation.....................34 4.2 Power Options......................35 4.2.1. Internal Battery.....................35 4.2.2. AC Power......................36 4.2.3. DC power......................36 4.3 Additional services....................36 4.3.1. Embedded SFTP server..................36 5. The Web User Interface (WebUI)..............39 5.1 Start.........................39 5.1.1. Manual recording....................39 5.1.2.
- Page 4 - 4 - 5.6 Master functionality....................72 5.6.1. Config / Status and Master/slave configuration............73 5.6.2. Common Trigger....................73 5.6.3. Common Alarm 1 and 2..................75 5.7 Recording List......................75 5.8 System warning......................77 5.9 Rest API........................78 6. Available spare parts and accessories............79 Appendix A: SAFETY INSTRUCTIONS............80 MR3000DMS_v2_0_rev1.odt subject to technical change without notice...
-
Page 5: Introduction
(FO), internal battery, relays and integrated terminals. The MR3000DMS is dedicated to dams, but it can be used in other types of structures, like buildings, bridges and tunnels. In the user manual, the name “DMS” will be used to indicate the MR3000DMS. -
Page 6: Features
Features Main features are: Compact unit with integrated sensor, digital recorder, battery and wired connectivity ARM/DSP Technology Tri-axial MEMS accelerometers Removable 4 GB SD-Card storage (up to 32 GB) Internal battery 3 settable alarm relays ... -
Page 7: Hardware
HARDWARE Mechanical Drawing – Overview Figure 2.1.1. Mechanical drawings of them MR3000DMS: top view (a), front view (b). -
Page 8: Connectors
Relays for relay outputs. • Figure 2.2.1. Face of MR3000DMS showing the sockets for Relays, Power, LAN and GPS, in case of FO kit. Figure 2.2.2. Face of MR3000DMS showing the sockets for Relays, Power, LAN and GPS, in case of LAN kit,... -
Page 9: Power
Status LEDs There are three status LEDs. The green RUN LED is on if the MR3000DMS is active and blinking while the unit is starting up. The yellow DATA LED is on if the MR3000DMS is recording an event. The red ERROR LED indicates if any error or warning occurs on the MR3000. If it blinks slowly, then a warning has been detected, if it is permanently ON (red colour) then an error has been detected. -
Page 10: List Of Errors And Warnings
Opening the Lid WARNING – Static Electricity The MR3000DMS contains CMOS devices and, when serviced, care must be taken to prevent damage due to static electricity. For a security reason, first the MR3000DMS should be disconnected from the AC. Successively you can open the lid and disconnect the fuse in order to protect all the internal components from any wrong manipulations that might occur. - Page 11 7) Device switch (fuse) 8) OverVoltage Protection (OVP) 9) Relays terminals 10) AC/DC converter 11) DC board For the DC version, the AC/DC converter and the over-voltage protection are replaced by a dedicated board for an external DC power.
- Page 12 Figure 2.4.1. Internal view of the MR3000DMS with AC power.
-
Page 13: Internal Display
2.4.1. Internal display The LCD of the MR3000DMS shows the most important settings and parameters. In particular, there are two types of screen, that are changing constantly. The first one, as can be seen in Figure 2.4.3a, indicates general parameters related to the MR3000DMS:... -
Page 14: Mems Acceleration Sensor
'STA/LTA', this is clearly shown on the LCD display LINE 4. Number of events recorded on the SD card. Figure 2.4.3. First (a) and second (b) screen of the internal display of the MR3000DMS. The second screen (Figure 2.4.3b) shows the information related to the last event: LINE 1. -
Page 15: Sd Flash Card
2.4.3. SD Flash Card The MR3000DMS contains an SD-card slot. The SD Flash Card in this slot is used to store the recordings. To remove the card, you have to push it down, it will then pop-up. NOTE: Ensure the MR3000DMS is turned off before removing and re-inserting the SD Card. -
Page 16: Battery
Between the relay terminals and the AC/DC converter, a fuse can be used simply to turn on and turn off the MR3000DMS. It is indicated with F1. It is a 1.6 AT /250 V fuse, with dimensions 5×20 When you open the MR3000DMS for the first time, you have to put it back in place, because it is provided as opened, such that the DMS is not powered. -
Page 17: Over-Voltage Protection (Ovp)
2.4.8. Over-Voltage Protection (OVP) The over-voltage protection (OVP) has the following characteristics: Tested according to IEC 61643-11 for Type I and II surge protection Pluggable arrester. If it is red instead of green the arrester should be changed. Figure 2.4.8. -
Page 18: 2.4.10. Ac/Dc Converter
2.4.10. AC/DC converter In Figure 2.4.10 it is possible to see the hardware structure and terminals related to the AC/DC converter. If an external fuse is necessary or utilized, minimum requirements need to be considered to avoid nuisance tripping of the circuit breaker. A minimum value of 10A B- or 6A C-Characteristic breaker should be used. -
Page 19: 2.4.12. Terminal Label
MR3000DMS. It is also represented in Figure 2.4.12. Figure 2.4.12. Label with information on the terminals of relay and power for: a) MR3000DMS with AC power; b) MR3000DMS with DC power. -
Page 20: 2.4.14. Installation
Figure 2.4.13. Axis orientation in case of horizontal and vertical installation. 2.4.14. Installation For a fixed installation of the DMS, it is possible to directly fix the DMS or to use a mounting plate. In the first case, the holes (number 1 in the Figures 2.4.14 and 2.4.15) close to the screws (number 2 in the same figures) can be used. - Page 21 Figure 2.4.15. Internal view of the DMS. Figure 2.4.16. Drawing of the DMS together with its mounting plate. The values are in mm.
- Page 22 In case of a mounting platform, the same holes are used to fix it to the MR3000DMS. This application must be preferred in cases where the surface of installation is not perfectly smooth. In Figures 2.4.16 and 2.4.17 it is possible to have all the information about the distances.
- Page 23 The typical installation on a dam is done on a concrete block, for a good coupling with the ground, and with the protection of a cabinet, as shown in Figure 2.4.19. Figure 2.4.19. Typical installation in a dam, with the MR3000DMS inserted in a protective cabinet, above a concrete block.
-
Page 24: Set-Up Of The Mr3000Dms
SET-UP of the MR3000DMS First of all, please connect the MR3000DMS to the main power or to a DC power, depending on the version purchased. In case no power is provided, the internal battery can guarantee an autonomy of about 40 hours. -
Page 25: Wired Connection Without Switch/Router
MR3000DMS and PC is possible. Now, you can simply enter the IP address displayed on the LCD of the MR3000DMS (inside the red box) in your Web browser. Generally your workshop router should have the following features: ... -
Page 26: Connecting To The Mr3000Dms In The Field (Remote Connection)
You can use an existing Internet access point at site (DSL, cable TV line, ...) and you simply connect the MR3000DMS with the router using the LAN/FO cable – as you would do in your office. If the router has the DHCP feature enabled – and you have enabled it in the DMS as well, the router will assign an IP address to the DMS. - Page 27 3. Link the MR3000 in one project 4. Click on the recorder name to access its setting More details can be found at scs.bartec-syscom.com or at the dedicated webpage on the Bartec Syscom website. Please contact support@bartec-syscom.com for any additional information.
-
Page 28: Operating With The Mr3000Dms
Before entering in details about the WebUI (Web User Interface), the configuration of the DMS for a monitoring session is explained. It is recommended to set-up the MR3000DMS in the office for the use in the field. Depending on the measurement task, you may consider the different power options. It is recommended to erase any obsolete files on the SD card before you use the DMS for a specific measurement. - Page 29 Figure 4.1.1. Setting of a fix IP address on a personal PC or laptop. Figure 4.1.2. Assignment of the IP address to a MR3000DMS, in case of a local network.
-
Page 30: Network Settings
MRs to use the IP address of this MR as NTP server (see chapter 5.3.2). Otherwise, in case of GPS, you need to put the IP address of the MR3000DMS which is connected to the GPS. In the example proposed, three MRs are connected on the same local network, and the IP address has been changed manually. - Page 31 Figure 4.1.4. Subsection dedicated to the setting of the common trigger.
-
Page 32: Alerts
Figure 4.1.5. Subsection dedicated to the common alarms. Successively, in the Common Alarm section, you define the conditions for the voting logic. The procedure is exactly the same as for the common trigger. Make sure to activate the Common Alarm in the tab Contacts to get a message if there is a common alarm. 4.1.3. -
Page 33: Measurements Settings
4.1.4. Measurements settings First the sampling frequency must be set up, then the trigger level. In the example, the trigger level is set at 10 mg on X and Y axes while 50 mg for the Z axis. The trigger is activated if one of the three axes exceed the respective threshold. -
Page 34: Site Installation
Figure 4.1.9. Set up of the alarm parameters. It is important also to program periodic test pulses, to verify the good functioning of the device. For additional information, please read Section 5.4.6. Figure 4.1.10. Screen dedicated to test pulse of the MR3000DMS. 4.1.5. Site installation Now the unit can be installed on site, in a convenient place for the connection to an AC outlet. -
Page 35: Power Options
Figure 4.1.11. Screen dedicated to the status of the MR3000DMS. Status tab (for all the details please refer to Section 5.2) should be open to check: 1) The status of the supply power; The free space on the SD card and its lifetime;... -
Page 36: Ac Power
4.2.2. AC Power In this case, you can simply connect the MR3000DMS to the main power. This solution is highly recommended. 4.2.3. DC power On request, the MR3000DMS may be powered also by DC power, as for example external power as solar panels. - Page 37 Now click on the Connect button and the following main screen appears. On the left side you see the file system of your PC on the right side the file system of the MR3000DMS. On the PC you should create a specific directory for each MR.
- Page 38 The first time you launch it, click on File->Site Manager..., then click on New Site. In the host field, enter the IP address of the MR3000DMS. For the protocol, choose SFTP. For the logon type, choose normal. Then, enter your login and password, and click Connect.
-
Page 39: The Web User Interface (Webui)
The Web User Interface (WebUI) Once the connection with the MR3000DMS is established, and the IP address of the MR3000DMS is known, the Web user interface (WebUI) must be opened. Just launch your favorite Web browser, and enter the IP address of the DMS in the address bar. Depending on your Web browser, you may have to enter the letters “http://”... -
Page 40: Trigger Recording
The trigger is a feature that allows the DMS to start recording if the signal reaches the threshold level. In this case the MR3000DMS is “triggered”. When the signal comes back below the threshold level, the trigger is “idle” – see section Activity on the Status screen. - Page 41 (=channel, e.g. Z vertical), or more. If you consider more than one Axis, you can decide if the MR3000DMS is triggered when all the axes are above the level, or just one of them. You choose it with the AND/OR Logic. A common setting is to consider all 3 axes, and trigger when any of them has reached the trigger level (“OR”).
-
Page 42: Timed Recording
STA/LTA is a trigger algorithm usually used in the field of weak-motion seismology. The STA/LTA continuously calculates the average values of the absolute amplitude of a seismic signal in two consecutive moving-time windows. The short time window (STA) is sensitive to seismic events while the long time window (LTA) provides information about the temporal amplitude of seismic noise at the site. -
Page 43: Background Recording
Figure 5.1.4. Timed recording interface. 5.1.4. Background recording In background recording mode the DMS records the peak values within a given time window. Please note that event recording is not affected by the peak recording – both services may run simultaneously. -
Page 44: Status
ID contains: • Name of the MR3000DMS (by default this is mr3000, followed by a dash and its serial number). You may change the name, according to your needs (see Section 5.4.1). Comment, for example a description of the location where you have installed the DMS. -
Page 45: System
Indicators shows the current temperature inside the MR, the input voltage and the uptime (time since the last boot of the system). Figure 5.2.1. Status interface. System In this part, you find all the settings of the different hardware interfaces and software services of the MR3000DMS. -
Page 46: Sd Card
5.3.1. SD Card This subsection shows the capacity of the memory card and the amount of memory available. Moreover, and indication of the remaining lifetime is displayed. You can format the memory SD card with the relative button: this erases ALL the data memorized on the card. - Page 47 As a second option, you may adjust the clock at once with an NTP server using the Internet connection. In the pop-up windows you have to set-up appropriate NTP servers. Alternatively the time can be set manually, and this works in every situation (i.e. without connection to the Internet).
-
Page 48: Lan
Figure 5.3.2. Subsection dedicated to the time synchronization in case of mode “Disabled” and mode “Network (NTP)”. 5.3.3. In this subsection, the settings for the Ethernet port (interface for wired connection) are shown. Mode is as follows: DHCP means that the DMS will try to get an IP address by sending DHCP requests. Select this option if you connect the DMS to a network with a DHCP server. -
Page 49: Ddns
The Netmask is 255.255.255.0 by default, and should remain like this except if you know exactly what you're doing. The Gateway address must be filled if you connect the DMS on a network. This is the IP address of the router. Same thing for the Nameserver. -
Page 50: Openvpn
dyndns no-ip dyndnsit changeip sitelutions Figure 5.3.4. Subsection dedicated to the DDNS. 5.3.5. OpenVPN VPN stands for Virtual Private Network. With this service, you will be able to communicate with the DMS when it is out in the field where it neither has a public (accessible from the WEB) nor a static (not changing) IP address. -
Page 51: Mail
In this section, you can configure the e-mail settings, in order to receive automatically mails from MR3000DMS. For this purpose you need an e-mail account and Internet access for the DMS-– check with the PING function as described in Section 5.3.10 You have to enter the access data of your e-mail account, i.e User address (e-mail address of your... -
Page 52: Ftp Send
DMS data easily available, as the access to the data on the server is much faster than to retrieve the data from the MR3000DMS. First you have to set-up the access to your FTP server in the FTP server settings: ... - Page 53 In Push mode the DMS will push a new event file to the FTP server as soon as recording of the file is done. The current background file may be updated continuously on the FTP server. In User parameters > Advanced settings – see chapter 5.4.8 - you specify how often the current background file is updated on the FTP server.
-
Page 54: Scs Cloud
The MR3000 can be connected to the SCS (Syscom Cloud Software) to easily visualize the data coming from it. The web address of the cloud software is http://scs.bartec-syscom.com. The MR must have internet connection to communicate with the SCS. Please see the related tutorial video “LINK A MR3000 TO THE SCS”... -
Page 55: Authentication
For any additional information on the SCS cloud software, please refer to the dedicated page on website or visit http://scs.bartec-syscom.com. 5.3.9. Authentication Here you can change the password of the DMS. The password is used for the WebUI access and for the SFTP service (see chapter 4.3.1). -
Page 56: 5.3.10. Upgrade
“Upgrade from files”. If the extension .txt is automatically added by your operating system (e.g. Windows), the please delete it. Figure 5.3.10. Subsection dedicated to the Upgrade. NOTE: It is recommended to upgrade the MR3000 at the end of a monitoring session. Please contact support@bartec-syscom.com for further clarifications. -
Page 57: Maintenance
5.3.11. Maintenance Here you may generate a report of the system to make further investigations in case of trouble. The report is automatically downloaded to your PC. NOTE: The log files and other variables used to generate the Diagnostic report are in volatile memory, do not switch of the DMS before the report is generated. -
Page 58: 5.3.12. Sensor
Figure 5.3.12. Subsection dedicated to the import of user parameters. 5.3.12. Sensor Inside the current section, there is one subsection dedicated to the sensor of the MR3000DMS, which is an internal triaxial accelerometer. Inside this section, the sensor model, the type, unit of measure and the serial number are indicated. -
Page 59: Monitoring
With modify settings you can modify the unit of measure of the sensor. It is possible to select metric or imperials units, in particular mg (default value) or m/s2 or in/s2. NOTE: if you do not want to change the settings please click on CANCEL, because otherwise the MR will reboot. -
Page 60: User Parameters
Higher sampling rates accumulate more data and create larger files. In the MR3000DMS there is a band-pass trigger filter on the data between 0.5 and 15 Hz. This means that en event is created only if both the conditions are fulfilled: the trigger level is exceeded;... -
Page 61: Alarm
Figure 5.4.2. Subsection dedicated to system acquisition. 5.4.3. Alarm The alarm service checks if the vibration exceeds the defined alarm threshold levels. In this case, the notification service of the MR3000 sends an e-mail to the people listed in contacts where Alarm 1 or Alarm 2 have been checked (see chapter 5.4.4). - Page 62 It is possible to define two levels of alarms: alarms 1 and alarm 2. They can be configured completely independently. In the field “Based on”, the alarm can be activated on the trigger or on the background recording. In the following, let us analyze the two situations separately. Trigger recording Figure 5.4.3 shows the possibilities for the choice of the alarm limit, when the alarm has been selected on the trigger recording.
- Page 63 points for each channel. A maximum number of 8 points can be set for each channel. Moreover, each channel can be set completely independently, meaning that X can have 2 points, Y can have 4 points and Z no points. The button “Restore” allows to reset the name and the values defined. NOTE: If an alarm is defined on a user-defined norm, it is not possible to set the trigger value higher than the alarm threshold.
- Page 64 If the user defined norm is activated, in the section Start → Background recording, a mode including the dominant frequency must be also activated (Subsection 5.1.4). Figure 5.4.6. Configuration of the alarms causing a warning. Figure 5.4.7. a) Setting of the background recording; b) Warning message caused by the definition of the alarm as in Fig.
-
Page 65: Notification
NOTE: A configuration like in Fig. 5.4.6 is not correct because the MR3000 is not able to save the vector sum and the dominant frequency at the same time (Subsection 5.1.4). For example, if the option “Peak + Dominant Frequency” has been selected, then a warning indicating that Alarm 1 cannot happen is shown (Fig. - Page 66 Contacts In this subsection, it is possible to add Contacts for the notification service. Contacts are people who receive notification from the MR3000. To add a new contact click on the Add button. To edit a contact, just click the corresponding line. Clicking the Del button will delete the corresponding contact.
- Page 67 Trigger event • Alarm 1 • Alarm 2 • Daily messages • Test pulse • SD Card state of health • Battery state of health • In Fig. 5.4.10, two windows related to the different messages are shown. In case of Alarm 1, Alarm 2 and Daily message, the user can also add a comment, that will be displayed in the message.
-
Page 68: Daily Message
5.4.5. Daily message This service sends you an e-mail notification every day. You can set-up the Time when you wish to receive this notification. Some information is automatically appended: the number of events, the memory available, the lifetime of the SD-Card and the background mode. The recipients of this message are set-up in the section contacts –... -
Page 69: Relays
In Event recording settings you can choose between two file formats: XMR, the proprietary format prepared by Bartec Syscom for events. ASCII, a simple format where all the data recorded is put in a simple text file. It is convenient if you plan to use software like GNU Octave, Matlab or other commercial software to view and process your data. -
Page 70: View
In Background recording settings you can choose between two file formats: BMR, the proprietary format prepared by Bartec Syscom for background files. ASCII format In Traffic settings you can set-up how often the background files are pushed to the server, choosing a value included from 1 to 60 minutes. -
Page 71: Background
the line, with the same color but lighter shade, the envelope of the signal (with the true peaks) is drawn. The Vertical zooming, or simply zoom, is exactly what its name suggests. A value of 1 means no zooming; a value of 100 means that signal is multiplied by 100. Figure 5.5.1. -
Page 72: Master Functionality
– called Slaves. Communication in the network is handled by the Master. With this feature up to 32 MR3000DMS or MR3000C can be integrated in a network to perform common sampling, common trigger and common alarm. -
Page 73: Config / Status And Master/Slave Configuration
5.6.1. Config / Status and Master/slave configuration Here you define which MRs are part of the network. Simply add the IP-address of the MR. The Master itself must be included (simply check the itself box). The IP address of the Master could be shown as 127.0.0.1 (localhost) or as its own IP address (Figure 5.6.1). - Page 74 Figure 5.6.2. Subsection dedicated to the setting of the common trigger. Click on the Add button to set-up a new condition. Click in the Edit combination section the select box for the single MRs. In the column Name you may enter a mnemonic for this condition (e.g. MR in cellar).
-
Page 75: Common Alarm 1 And 2
5.6.3. Common Alarm 1 and 2 Common Alarm means that there is a voting logic for the alarms. Here you define the conditions for the voting logic. The procedure is exactly the same as for the common trigger. Make sure to activate the Common Alarm in the tab Contacts to get a message if there is a common alarm. - Page 76 software to visualize the data) installed, the file (peak or event) is shown immediately. You may use EAWlight to perform a Frequency Analysis (FFT) of the waveform and to print the waveform. You may select several files and then click on the Download button. The files are packed in a single Zip-File and transferred to the PC.
-
Page 77: System Warning
Figure 5.7.2. Subsection dedicated to the filters for the recording list. System warning In case there are anomalous settings about the parameters of the MR3000DMS, warning or errors will be displayed in order to alert the user. For example, if the user does not activate the alarms but he wants to receive the mails also with notification of the alarm then, immediately after confirmed the operation with the “Apply”... -
Page 78: Rest Api
Figure 5.8.2. Automatic warning produced by the software. Rest API The REST API functionality have been added on the firmware 1.6. Please contact Bartec Syscom for more information at info@bartec-syscom.com. -
Page 79: Available Spare Parts And Accessories
Available spare parts and accessories In the following, a list of spare parts is shown. Battery (12V / 12 Ah) 74.21.1024 Backup battery (3V) 74.21.0018+ Fuse (1.6AT / 250V 5×20 mm) 74.15.0005+ Over Voltage Protection, pluggable arrester 87.00.0301 SD card 4GB (SWISSBIT) 74.90.0035+ Mounting Plate + screws and bolts 13.00.0048... -
Page 80: Appendix A: Safety Instructions
Appendix A: SAFETY INSTRUCTIONS Introduction Thank you for choosing this Bartec Syscom product. Before operating it, please read this manual thoroughly and retain it for future reference. Note - Before operating the product, please read "Safety information". - Pictures and illustrations used in this manual are for reference only and may differ from actual product appearance. - Page 81 - Unplug the mains plug and clean it regularly. If the plug is covered with dust and it picks up moisture, its insulation may deteriorate, which could result in a fire. Note - Do not use the supplied mains lead on any other equipment. - Do not pinch, bend or twist the mains lead excessively.
- Page 82 Disposal of the product Disposal of Old Electrical & Electronic Equipment (Applicable in the European Union and other European countries with separate collection systems) This symbol indicates that the product shall not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment.
