Connecting RX wires
The wires are labeled from the factory. If you are using the DX18, the program is available on
a SD card from BVM. Follow the chart below to connect the servos.
DX18 Connection Chart
RX Port
Throttle
Aileron
Surface
Throttle
Right Ail
RX Port
Aux4
Aux5
Surface
Right
Nose
Body
Steering
Flap
DX18 and DX18QQ Transmitter File
The BVM Demo models are setup on Spektrum DX18 transmitters. The file included on the
SD card has all the mixes, rates, expos, and settings done for you. Setting the sub trim and
travel adjustment must be accomplished by the modeler for the specific aircraft. Each aircraft
is tested at the factory using a similar program.
Important!!! Check the directions of all flight controls before each flight.
Switch/Lever/Trimmer Channel
Switch A
Switch B
Switch C
Switch D
Button I
L. Trim
Switch E
Switch F
Switch G
Switch H
Right Lever
BVM ®2015
Elevator
Rudder
Elev
Rudder
X+1
X+2
Gyro Gain
Speed
Brake
X+3
X+5
Elevator Rates
Flaps and Body Flaps
Throttle Cut
Steering Trim/Aux 5
X+2/Speed Brake
Aileron Rates
Rudder Rates
X+6/Smoke
X+2/Brakes
Gear
Aux1
Left Flap
Left Ail
X+3
X+4
Gear
Wheel Brake
Seq.
Output
Landing Gear, Down is Down
Lights, Down is off, Up is on
Up (0) is High
Up is Normal flight
Mid is Take off Flap
Down is landing flap
Throttle Cut
Down for Right Steering Trim
Up for Left Steering Trim
Up is speed brake up
Up (0) is High
Down/Away (0) is High
Down (0) Smoke off
Up (1) Smoke on
Up/Away – Brakes off
Down/Pulled – Brakes on
40
Aux2
Aux3
Right Flap
Left Body
Flap
X+5
X+6
Lights
Smoke
