- Page 1 Em104P-i2313 Wide Range Temperature ETX-PC/104-Plus Complex User’s Manual Version 1.2 2021.03...
- Page 2 Revision History Version Release Time Description Nov, 2014 Initial release 1.Modify Orderding information - Delete CBK-16-1100-02 Sep,2016 - Add CBK-16-1100-01 2.Modify LVDS’s pin definition 1. Update the Windows 10 driver 2. 2.1 Block Diagram: Update “Innodisk 6DB368L048”, “IDE”, “Realtek ALC886” and “Realtek RTL8106E”.
-
Page 3: Table Of Contents
Contents Preface .....................iii Copyright Notice ............... iii Declaration of Conformity ............iii CE ..................iii RoHS ................. iv SVHC / REACH ..............iv About This User’s Manual ............v Warning ..................v Replacing the Lithium Battery ........... v Technical Support ..............v Warranty ................... - Page 4 Contents 3.2.9. Video Configuration ..........29 3.2.10. SATA Configuration ..........31 3.2.11. ACPI Table/Feature Control ........32 3.2.12. Super I/O Configuration ........32 3.3. Security ................33 3.4. Power ................34 3.4.1 Advanced CPU Control ...........35 3.5. Boot ..................37 3.6. Exit ...................39 Appendix ..................41 Appendix A. Watchdog Timer (WDT) Setting ......42 - ii -...
-
Page 5: Preface
Preface Copyright Notice All Rights Reserved. The information in this document is subject to change without prior notice in order to improve the reliability, design and function. It does not represent a commitment on the part of the manufacturer. Under no circumstances will the manufacturer be liable for any direct, indirect, special, incidental, or consequential damages arising from the use or inability to use the product or documentation, even if advised of the possibility of such damages. -
Page 6: Rohs
RoHS ARBOR Technology Corp. certifies that all components in its products are in compliance and conform to the European Union’s Restriction of Use of Hazardous Substances in Electrical and Electronic Equipment (RoHS) Directive 2002/95/EC. -
Page 7: About This User's Manual
Preface of SVHC (Substances of Very High Concern) in (EC) 1907/2006 (REACH --Registration, Evaluation, Authorization, and Restriction of Chemicals) regulated by the European Union. All substances listed in SVHC < 0.1 % by weight (1000 ppm) About This User’s Manual This user’s manual provides general information and installation instructions about the product. -
Page 8: Warranty
Preface Warranty This product is warranted to be in good working order for a period of two years from the date of purchase. Should this product fail to be in good working order at any time during this period, we will, at our option, replace or repair it at no additional charge except as set forth in the following terms. -
Page 9: Chapter 1 Introduction
Chapter 1 Introduction Chapter 1 - Introduction... -
Page 10: Packing List
Before starting with the installation, make sure the following items are shipped. If any item appears damaged or is missing, contact your vendor immediately: Em104P-i2313 PC/104 plus module kit: 1 x EmETX-i2304 ETX CPU Module 1 x PBE-1100-RG R3.3 ETX 3.0 Carrier Board... - Page 11 Introduction Driver (7.8A) Installation Windows 7 Driver Path \Audio\32bit_Win7_R273 AUDIO \Audio\64bit_Win7_R273 CHIPSET \Chipset\Win32_64_10.1.17 Ethernet \Ethernet\Install_Win7_7076_11222013 \Graphic\32bit_36.15.0.1073 Graphic \Graphic\64bit_37.15.0.1073 Processor IO \Processor IO \TXE Patch USB3.0 \USB3.0 Windows 10 Driver Path \Audio\Win32 AUDIO \Audio\Win64 GPIO I \GPIO I2C\windows10 32_64 \Graphic\Win32 Graphic \Graphic\Win64 \INF\Win32_64_10.1.17 \LAN\0023-Install_Win10_10025_03202018\Install_Win10_10025_03202018...
-
Page 12: Specifications
Introduction 1.3 Specifications Form Factor ETX-PC/104-Plus Complex CPU Module Intel Atom™ Processor E3825 dual-core ® 1.33GHz or E3845 quad-core 1.91GHz 1 x 204-pin SO-DIMM socket, up to 8GB DDR3L Memory 1333 MT/s SDRAM Graphic Chipset SoC integrated Intel Gen 7 graphic ®... -
Page 13: Board Dimensions
Introduction 1.4. Board Dimensions 99.19 13.46 9.91 13.72 87.38 89.92 92.5 92.5 99.19 13.46 Unit: mm - 5 -... - Page 14 This page is intentionally left blank. - 6 -...
-
Page 15: Chapter 2 Installation
Chapter 2 Installation Chapter 2 - Installation... -
Page 16: Block Diagram
Installation 2.1. Block Diagram Single Channel DDR3L 1 x SO-DIMM 1333MT/s socket Connector Dual Cannels LVDS USB ports x4 24-bit LVDS PTN3460BS 4 x USB Analog R.G.B. Audio Realtek AC Link Audio COM1, 2 ALC886 COM1~2 Intel Atom ® LPT1/ FDD E3825 1.33GHz Primary E3845 1.91GHz... -
Page 17: Jumpers And Connectors
Installation 2.2. Jumpers and Connectors 2.2.1. Quick Reference Jumpers Label Function (29)JCFD1 CF IDE1 mode Selection (27)JBLON1 LCD Backlight Selection (26)JBAT1 Clear CMOS Setting (25)JWT1 WDT Mode Setting (24)JVLCD1 LCD Panel Voltage Selection (23)JRS2 COM2 RS-232/422/485 Selection Connectors Label Function (1)DIO1 Digital I/O Connector (2)AUDIO1... -
Page 18: Jumpers & Connectors Location
Installation 2.2.2. Jumpers & Connectors Location Em104P-i2313 DIO1 USB1 USB2 AUDIO1 VGA1 PC104+ FAN1 COMB JCFD1 COMA CFD1 JBLON1 JBAT1 LPT1 JWT1 JVLCD1 KBM1 JRS2 FAN2 LAN1 PWR1 LAN2 JCOM1 LANLED CONA1 JFRT1 IDE1 LVDS1 INV1 - 10 -... -
Page 19: Jumpers
Installation 2.2.3. Jumpers JCFD1: CF IDE1 mode Selection (29) Connector type: 2.00mm pitch 1x2-pin headers. Mode Short Master Open Slave (Default) JBLON1: LCD Backlight Selection (27) The LCD panel backlight active mode could be selected by JBLON1 in High or Low. Connector type: 2.00mm pitch 1x3-pin headers. -
Page 20: Connectors
Installation JVLCD1: LCD Panel Voltage Selection (24) The voltage of LCD panel could be selected by JVLCD1 in +5V or +3.3V. Connector type: 2.00mm pitch 1x3-pin headers. Voltage +3.3V (Default) JRS2: COM2 RS-232/422/485 Selection (23) It can be configured COM2 to operate in RS-232, RS-422 or RS-485 mode. Connector type: 2.00mm pitch 2x3-pin headers. - Page 21 Installation AUDIO1: AC97 Connector (2) Connector type: 2.00mm pitch 2x5 box headers. Pin Desc. Pin Desc. Line_In_Left Line_In_Right 9 10 Speaker Left Speaker Right USB1 ~ 2: USB Connectors (4, 3) Connector type: 2.00mm pitch 2x5-pin headers. Pin Desc. Pin Desc. USBD- USBD- USBD+...
- Page 22 Installation COM A~B: RS-232 Connectors (6, 7) Connector type: 2.00mm pitch 2x10-pin box headers. Pin Description Pin Description DCD#1 / 3 RXD1 / 3 TXD1 / 3 DTR#1 / 3 DSR#1 / 3 RTS#1 / 3 CTS#1 / 3 RI#1 / 3 10 N/C 11 DCD#2/ 4 12 RXD2/ 4...
-
Page 23: Kbm1: Keyboard & Mouse Connector (9)
Installation KBM1: Keyboard & Mouse Connector (9) Connector type: 2.0mm pitch 1x6-pin box wafer connector. Description KB_DATA MS_DATA KB_CLK KB_VCC MS_CLK FAN2: Fan Power Connector (10) FAN2 is a 3-pin headers for the fan. The fan must be a +12V fan. Description +12V TV1: TV-out Connector (11) - Page 24 Installation PWR1: Power Supply Connector (12) Connector type: Terminal blocks. Description +12V JCOM1: RS-422/485 Connector (13) Connector type: 2.00mm pitch 1x4 box wafer connector. Pin RS-422 RS-485 DATA+ DATA- JFRT1: Switches and Indicators (14) It provides connectors for system indicators that provides light indication of the computer activities and switches to change the computer status.
- Page 25 Installation LVDS1: LVDS LCD Connector (15) The LVDS connector on board 30-pin headers and supports 18/36-bit. Pin Desc. Pin Desc. TX2CLK+ 3 TX1CLK+ TX2CLK- 5 TX1CLK- TX2D0+ 9 TX1D0+ TX2D0- 11 TX1D0- TX2D1+ 15 TX1D1+ TX2D1- 17 TX1D1- TX2D2+ 21 TX1D2+ TX2D2- 23 TX1D2-...
- Page 26 Installation IR1: Infrared Connector (17) Connector type: 2.54mm pitch 1x5-pin headers. Description IRRX IRTX IDE1: Primary IDE Connector (18) Connector type: 2.00mm pitch 2x22-pin box headers Description Description RESET# DATA7 DATA8 DATA6 DATA9 DATA5 DATA10 DATA4 DATA11 DATA3 DATA12 DATA2 DATA13 DATA1 DATA14...
- Page 27 Installation LANLED: LAN LED Indicators (20) Connector type: 2.54mm pitch 2x2-pin headers. Pin Description -ACTLED -LILED LAN1~2: Ethernet Connectors (21, 22) Connector type: 2.00mm pitch 2x5-pin headers. Pin Desc. Pin Desc. TX_MDI0+ TX_MDI0- RX_MDI1+ MDI2+ MDI2- RX_MDI1- MDI3+ MDI3- N/C (Key) CFD1 : Compact Flash Disk socket (share with IDE1) (28) FAN1: System Fan Power Connector (30) FAN1 is a 3-pin headers for the CPU fan.
- Page 28 This page is intentionally left blank. - 20 -...
-
Page 29: Chapter 3 - Bios
Chapter 3 BIOS Chapter 3 - BIOS... - Page 30 BIOS The BIOS Setup utility is featured by Insyde BIOS to configure the system settings stored in the system’s BIOS ROM. Insyde BIOS is activated once the computer powers on. After entering the utility, use the left/right arrow keys to navigate between the top menus and use the down arrow key to access one.
- Page 31 BIOS Key Commands The BIOS Setup utility relies on a keyboard to receive user’s instructions. Hit the following keys to navigate within the utility and configure the utility. Keystroke Function ← → Moves left/right between the top menus. ↓ ↑ Moves up/down between highlight items.
-
Page 32: Main
BIOS 3.1. Main The Main menu displays some BIOS info and features the settings of System Date and System Time. The BIOS info displayed is: Info Item Description BIOS Version Delivers the computer’s BIOS version. Project name Delivers the name of the project Delivers the date and time when the BIOS Setup utility was Build Date and Time created/updated. -
Page 33: Advanced
BIOS 3.2. Advanced The Advanced menu controls the system’s CPU, IDE, Super IO, AHCI and USB. It also helps users monitor hardware health. - 25 -... -
Page 34: Boot Configuration
BIOS The featured submenus are: Submenu Description Boot Configuration See 3.2.1. Boot Configuration on page 26 IDE Configuration See 3.2.2. IDE Configuration on page 26 USB Configuration See 3.2.3. USB Configuration on page 26 Audio Configuration See 3.2.4. Audio Configuration on page 27 LAN Configuration See 3.2.5. -
Page 35: Audio Configuration
BIOS 3.2.4. Audio Configuration The featured settings are: Setting Description Audio Controller Enables/Disables Azalia Controller Azalia VCi Enable Enables/Disables Virtual Channel 1 of Audio Controller Azalia HDMI Codec Enables/Disables Internal HDMI codec for Azalia 3.2.5. LAN Configuration The featured settings are: Setting Description LAN Configuration... -
Page 36: Miscellaneous Configuration
BIOS 3.2.7. Miscellaneous Configuration The featured settings are: Setting Description / Available Options HPET - HPET support Enables/Disables HPET support in Windows XP Set the state of System when power is re-applied after a State After G3 Power failure (G3 state) Options are S0 State(default)/S5 State Clock Spread Spectrum Enables/Disables Clock Spread Spectrum... -
Page 37: Video Configuration
BIOS 3.2.9. Video Configuration Configure video settings The featured setting is: 3.2.9.1 Video Configuration Setting Description Set Logo & SCU Resolution. Logo & SCU Resolution Options are Auto/640 x480/800 x 600/1024 x 768 3.2.9.2 VBT Hook Configuration Setting Description Set the option of CRT. Configure CRT as Options are Default / CRT / No Device CRT EDID Support... - Page 38 BIOS 3.2.9.4 GOP Configuration Setting Description GOP Brightness Level Set the Brightness Level of GOP. GOP Driver Enables/Disables GOP Driver 3.2.9.5 IGD Configuration Setting Description Integrated Graphics Enables/disables Intergrated Graphics Device. Device Set IGD or PCI graphic device as the Primary Display. Primary Display Options are Auto/IGD/PCie.
-
Page 39: Sata Configuration
BIOS 3.2.9.6 IGD- LCD Control Setting Description Set mode of as the Primary Display. Force Lid Status Options are ON (default) / OFF / Auto. Set the mode of BIA. Options are Auto (default) /Disabled / Level 1 /Level 2 /Level 3 /Level 4 /Level 5. -
Page 40: Acpi Table/Feature Control
BIOS 3.2.11. ACPI Table/Feature Control Setting Description FACP - RTC S4 This function will be avalible only when ACPI is enabled. Wakeup Enables/disables S4 Wakup from RTC. This item is valid only for WIN2K and WINXP. Also, a frech install of APIC - IO APIC Mode the OS must occur when APIC mode is desired. -
Page 41: Security
BIOS 3.3. Security The Security menu sets up the password for the system’s administrator account. Once the administrator password is set up, this BIOS Setup utility is limited to access and will ask for the password each time any access is attempted. The featured setting is: Setting Description... -
Page 42: Power
BIOS 3.4. Power The Power menu sets up the power option of system The featured setting is: Setting Description Advanced See 3.4.1 Advanced CPU Control on page 35 CPU Control Enables or diables Wake on PME. Wake on PME Determines the action taken when the system power is off and a PCI Power Management Enable wake up event occurs. -
Page 43: Advanced Cpu Control
BIOS 3.4.1 Advanced CPU Control Setting Description Use XD Capability Enables or disables processor XD capability. Sets whether the processor should limit the maximum CPUID input value to 03h when the operating system queries it upon startup. Limit CPUID Max Select Enabled to allow a processor with Intel®... - Page 44 BIOS Boot Performance Select the performance state that BIOS will set before OS handoff Mode Enables/disables processor Turbo mode (EMTTM enabled is Turbo Mode required) C-States Enables/disables processor idle power saving states (C-states) Enhanced Enables/disables P-state transitions to occur in combination with C-States C-states.
-
Page 45: Boot
BIOS 3.5. Boot The Boot menu configures how to boot up the system such as the configuration of boot device priority. The featured settings are: Setting Description Boot type Set the boot type. Options are Legacy Boot Type. Allow InsydeH20 to Skip certain tests while booting . This will Quick Boot decrease the time need to boot the system. - Page 46 BIOS USB Boot Disables or enables booting to USB boot devices. Timeout Set the waiting seconds before booting the default boot selection Automatic Failover Enables/disables the Automatic Failover. Legacy Setting Description Normal Boot Menu Set the boot Menu. Options are Normal / Advance. Set the boot type order.
-
Page 47: Exit
BIOS 3.6. Exit The Save & Exit menu features a handful of commands to launch actions from the BIOS Setup utility regarding saving changes, quitting the utility and recovering defaults. The features settings are: Setting Description Exit Saving Changes Saves the changes and quits the BIOS Setup utility. Save Changes Without Exit Save Changes but does not quit the BIOS. - Page 48 This page is intentionally left blank. - 40 -...
-
Page 49: Appendix
Appendix Appendix - 41 -... -
Page 50: Appendix A. Watchdog Timer (Wdt) Setting
Appendix Appendix A. Watchdog Timer (WDT) Setting WDT is widely used for industrial application to monitor CPU activities. The application software depends on its requirement to trigger WDT with adequate timer setting. Before WDT timeout, the functional normal system will reload the WDT. The WDT never time-out for a normal system.
