Form Factor
Qseven
CPU Module
®
Video
Single Channel 18-bit
LVDS/ SDVO/ DDI port/
Analog RGB (Reserved-
pin)
I/O
USB/ SATA/ PCIex1/ LPC
♦ Technical Support
If you have any technical difficulties, please consult the user's manual first at:
ftp://ftp.arbor.com.tw/pub/manual
Please do not hesitate to call or e-mail our customer service when you still can not
find out the answer.
http://www.arbor.com.tw
E-mail: info@arbor.com.tw
FCC Class A
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions : (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Copyright
2013 All Rights Reserved.
®
EmQ-i2506
CPU
Soldered onboard Intel
Atom™ N2600 processor
LAN
Intel
82583V Gigabit
®
Ethernet
- 1 -
Qseven
CPU Module
®
Quick Installation Guide
Chipset
Intel
PCH NM10
®
®
Audio
HD Audio Interface
4041250600110P
Version 1.1
Advertisement
Table of Contents
Related Manuals for Arbor Technology EmQ-i2506
Summary of Contents for Arbor Technology EmQ-i2506
-
Page 1: Quick Installation Guide
EmQ-i2506 Qseven CPU Module ® Quick Installation Guide Version 1.1 Form Factor Chipset Qseven CPU Module Soldered onboard Intel Intel PCH NM10 ® ® ® Atom™ N2600 processor Video Audio Single Channel 18-bit Intel 82583V Gigabit HD Audio Interface ®... -
Page 2: Packing List
Packing List Before starting to install the single board, make sure the following items are shipped: ® 1 x EmQ-i2506 Qseven CPU Module 1 x Driver CD 1 x Quick Installation Guide Ordering Information EmQ-i2506 Intel Atom™ N2600 1.6GHz Qseven CPU module ®... -
Page 3: Specifications
Specifications Form Factor Qseven CPU Module ® ® Soldered onboard Intel Atom™ N2600 1.6GHz processor Chipset Intel PCH NM10 ® System Memory Soldered onboard 2GB DDR3 SDRAM Ethernet controller 1 x Intel 82583V PCIe Gigabit Ethernet ® BIOS AMI PnP Flash UEFI BIOS Storage 2 x Serial ATA ports w/ 300MB/s HDD transfer rate Universal Serial Bus... -
Page 4: Board Dimensions
Board Dimensions 32.77 5.10 5.00 33.53 70.00 1.20 13.50 54.00 5.00 Unit: mm - 4 -... - Page 5 Heatsink Installation 1. Put the heatsink and screw it on in the direction shown in the figure below. 2. There are two approaches to install the heatsink. 2.1. Insert four screws downward into the holes and turn them tightly. 2.2. Insert two screws downward and two screws upward into the holes and turn them tightly.
-
Page 6: Connector Pin Assignments
Connector Pin Assignments Note: A pin with a remark “N/C“ is a pin that the signal isn’t available on this board while the remark beyond the bracket delivers the consortium-specified definition. Signal Signal Signal Signal HDA_SDI I2C_CLK (N/C) GBE_MDI3- GBE_MDI2- HDA_SDO I2C_DAT (N/C) GBE_MDI3+... - Page 7 Signal Signal Signal Signal DP3+ SDVO_INT+ (N/C) DP3- SDVO_INT- (N/C) SPI_MOSI SPI_CS0# SPI_MISO SPI_CS1# (N/C) DP1+ SDVO_FLDSTALL+/DPAUX+ SPI_SCLK MFG_NC4 DP1- SDVO_FLDSTALL-/DPAUX- VCC_5V_SB VCC_5V_SB MFG_NC0 MFG_NC2 DP2+ SDVO_TVCLKIN+ (N/C) MFG_NC1 MFG_NC3 DP2- SDVO_TVCLKIN- (N/C) SDVO_R+/DP0+ SDVO_CTRL_DAT SDVO_R-/DP0- SDVO_CTRL_CLK HDMI_HPD# DP_HPD# PCIE_CLK_REF+ PCIE_WAKE# PCIE_CLK_REF- PCIE_RST#...
- Page 8 This page is intentionally left blank. - 8 -...
