EmNANO-i2800
85
Form Factor
COM Express® Mini
Type 10 CPU Module
LAN
Intel i210 Series GbE
controller
♦ Technical Support
If you have any technical difficulties, please consult the user's manual first at:
http://www.arbor-technology.com
Please do not hesitate to call or e-mail our customer service when you still can not find
out the answer.
http://www.arbor-technology.com
E-mail: info@arbor.com.tw
♦ Declaration of Conformity
FCC Class B
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions : (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
Copyright® All Rights Reserved.
Mini COM Express® Type 10 CPU Module
CPU
Intel Elkhart Lake SoC
processor
Audio
HD Audio Link
- 1 -
Quick Installation Guide
Video
DDI port, LVDS
I/O
USB/ SATA/ I
4040280000100P
Version 1.0
C / TPM
2
85
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Arbor Technology EmNANO-i2800
Summary of Contents for Arbor Technology EmNANO-i2800
- Page 1 EmNANO-i2800 Mini COM Express® Type 10 CPU Module Quick Installation Guide Version 1.0 Form Factor Video Intel Elkhart Lake SoC DDI port, LVDS COM Express® Mini processor Type 10 CPU Module Audio Intel i210 Series GbE HD Audio Link USB/ SATA/ I...
-
Page 2: Packing List
The Ultra-small COM Express® Mini Module EmNANO-i2800 is a COM Express® Mini Type 10 module. The module size is 55 mm x 84 mm, which is the smallest in ARBOR’s COM Express® product lineup, next to the Basic size (125 mm x 95 mm) and Compact size (95mm x 95mm) form factors. -
Page 3: Specifications
Specifications Form Factor COM Express® Mini Type 10 CPU Module ® Soldered onboard Intel ® Atom x6211E 1.3GHz Dual cores TDP 6W ® Atom x6413E 1.5GHz Quad cores TDP 9W Soldered onboard LPDDR4 3200MT/s 4GB / 8GB SDRAM Memory BIOS AMI UEFI BIOS 8 x USB 2.0 ports USB Port... -
Page 4: Ordering Information
To install the drivers, please visit our website at www.arbor-technology.com and download the driver pack from the product page. Ordering Information Mini COM Express Type 10 Intel Elkhart Lake ATOM x6211E EmNANO-i2800-WT-x6211E-4G CPU Module w/4G memory down,-40~85 Mini COM Express Type 10 Intel Elkhart Lake ATOM x6413E EmNANO-i2800-WT-x6413E-8G... -
Page 5: Com Express Connector
COM Express Connector - 5 -... -
Page 6: Board Dimensions
Board Dimensions Ø2.7* Ø6.5 42.22 Unit: mm - 6 -... - Page 7 COM Express® Mini Type 10 AB Connector Note: A pin with a remark “(N/C)“ is a pin that the signal isn’t available on this board while the remark beyond the bracket delivers the consortium-specified definition. B1 GND GND A1 B2 GBE0_ACT# GBE0_MDI3- A2 B3 LPC_FRAME# GBE0_MDI3+ A3...
- Page 8 B56 RSV16 (N/C) RSV12 (N/C) A56 B57 GPO2/SD_WP GND A57 B58 PCIE_RX3+ PCIE_TX3+ A58 B59 PCIE_RX3- PCIE_TX3- A59 B60 GND GND A60 B61 PCIE_RX2+ PCIE_TX2+ A61 B62 PCIE_RX2- PCIE_TX2- A62 B63 GPO3/SD_CD# GPI1/SD_DATA1 A63 B64 PCIE_RX1+ PCIE_TX1+ A64 B65 PCIE_RX1- PCIE_TX1- A65 B66 WAKE0# GND A66...
-
Page 9: Block Diagram
Block Diagram LPDDR4-3200MT/s, upgradable to 8GB Onboard LPDDR4 8GB/4GB SDRAM 1 x DDI0 Single Channel 24-bit LVDS PTN3460 HD Audio Link 4 x PCIex1 SATA 0, 1 6GB/s ports Intel® 8 x USB 2.0 Elkhart Lake 2 x USB 3.0 SMBus eSPI LPC I/F...
