Note
An additional software license "ibaPDA-Request-TDC" is required in order to use the
SD-/TDC request function. It must be enabled on the iba software dongle.
The service function blocks required for the request function are included in the iba
function block library FBAPDA. You find the library on the DVD-ROM delivered with
ibaPDA.
Other documentation
The configuration of the request function is described in the "ibaPDA-Request-SD-
TDC" manual.

Front view

5.4
Figure 2:
10
Manual
Front view
Issue 1.2
1 7-segment display
2 Device status LEDs
3 FO connector (SC technology)
4 FO connector (SC technology)
ibaFOB-TDCexp
