Display and Key Pad

Pro mode is when configuration menu is entered to program the indicator. RUN is the
normal mode in which display shows the reading according to configuration and input signal
value.
2
3
# Description
4 digit display Red Shows value according to
1
2 Minus sign
3 Key Pad
4 Setpoint 1 LED
5 UP key
6 SHIFT key
7 DATA/ENTER key Changes to PRO mode.
8 Setpoint 2 LED
Free space for
9
units label
User Manual - DPM2-E Series Electrical Panel Meters
DATA
UP SHIFT
1
ENTER
4
5 6
Programming Panel
Run Mode
Shows steps and data during configuration.
configuration.
Illuminates for negative
Illuminates for negative values.
readings.
---
Illuminates when setpoint
Illuminates when setpoint 1 turns active.
1 turns active.
Shows setpoint value. Increases value of active
No application
digit.
Displays maximum and
minimum stored values.
After 3s of pressing, sets
Shifts active digit to the next right digit.
maximum and/or minimum
memorized value to
current display value.
Validates selected data and parameters.
Moves one step forward in configuration menu.
Changes to RUN mode.
Illuminates when Setpoint
Illuminates when Setpoint 2 turns active.
2 turns active.
---
DPM2-E Electrical User Manual, 1st Edition
