InP
UdC UAC

DC and AC Voltage

UdC
600
Available range options for DC and AC input voltage are identical:
Signal Ranges:
V DC: ±600V, ±200V or ±20V
V AC: 0-600V, 0-200V or 0-20V

DC and AC Current

AdC AAC
5A 1A
Available range options for DC and AC input current are identical:
Signal Ranges:
A DC: ±5A, and ±1A
A AC: 0-5A and 0-1A
mV DC: ±100mV and ±60mV Shunts
mV AC: 0-100mV and 0-60mV Shunts
User Manual - DPM2-E Series Electrical Panel Meters
AdC AAC
UAC
200 20
100 60
