Table 35: 750 W Power Supplies: Packaged Dimensions
750 W power supply – AC
front-to-back or back-to-front airflow
750 W power supply – DC
front-to-back or back-to-front airflow
Table 36: 750 W Power Supplies: Packaged Weight
750 W power supply – AC
front-to-back or back-to-front airflow
750 W power supply – DC
front-to-back or back-to-front airflow
Table 37: Power Specifications (AC Power Supplies)
Voltage input range
Nominal input ratings
Nominal input current at full loads
Line frequency range
Maximum inrush current
Output
Power supply input socket
Power cord input plug
Power cord wall plug
Power supply cord gauge
Efficiency
Table 38: Power Specifications (DC Power Supplies)
Nominal input
DC Voltage input range
Inrush Current
VSP 7400 Series Switches: Hardware Installation Guide
Height: 44.5 cm (17.52 in)
Width: 27.5 cm (10.83 in)
Depth: 42.5 cm (16.73 in)
Height: 44.5 cm (17.52 in)
Width: 27.5 cm (10.83 in)
Depth: 42.5 cm (16.73 in)
10.22 kg (22.53 lb)
10.50 kg (23.15 lb)
85 to 264 V
100-140/200-240V , 10/5.36A max., 50/60Hz
10 A at 90 V (low-line)
3.7 A at 230 V (high-line)
47 to 63 Hz
35 A
+12 V, 61.5 A
+12 Vsb, 3 A
Total output power not to exceed 750W
IEC 320 C14
IEC 320 C13
Refer to Power Cord Requirements for AC-Powered Switches and AC
Power Supplies on page 74.
2
18 AWG (0.75 mm ) up to 6 feet or 2 meters
or
2
16 AWG (1.0 mm ) over 6 feet
Low Line: 88% at 50% load and 86% at 100% load
High Line: 90% at 50% and 100% loads
-48 to -60 VDC, 20.4 A
-35 to -75 V
21 A peak
