Table 6: Cable Distances and Types (continued)
Standard
1000BASE-LX
(1300nm optical window)
1000BASE-ZX
(1550nm optical window)
100BASE-LX100
(1550nm optical window)
1000BASE-BX10
(1490nm optical window)
(1310nm optical window)
1000BASE-LX70
(1550nm optical window)
10/100/1000BASE-T SFP
10GBASE-T SFP+
10GBASE-SR SFP+
(850nm optical window)
10GBASE-LR SFP+
(1310nm optical window)
10GBASE-ER SFP+
(1550nm optical window)
40GBASE-SR4 QSFP+
(850nm optical window)
1000BASE-T
100BASE-TX
10BASE-T
1
Proprietary to Extreme Networks. Connections between two Extreme Networks 1000BASE-LX interfaces that use
10/125 µm single-mode fiber can use a maximum distance of 10,000 meters.
VSP 7400 Series Switches: Hardware Installation Guide
Media Type
50/125 µm multimode fiber
50/125 µm multimode fiber
62.5/125 µm multimode fiber
10/125 µm single-mode fiber
10/125 µm single-mode fiber
10/125 µm single-mode fiber
10/125 µm single-mode fiber
10/125 µm single-mode fiber
10/125 µm single-mode fiber
(1 Gbps link)
Category 5 and higher UTP cable
(100 Mbps link)
Category 5 and higher UTP cable
(10 Mbps link)
Category 5 and higher UTP cable
(10 Gb links)
Category 6A and higher UTP cable
62.5 mm multimode fiber
62.5 mm multimode fiber (OM1)
50 mm multimode fiber
50 mm multimode fiber (OM2)
50 mm multimode fiber (OM3)
10/125 µm single-mode fiber
10/125 µm single-mode fiber
50 mm multimode fiber (OM3)
50 mm multimode fiber (OM4)
Category 5 and higher UTP cable
Category 5 and higher UTP cable
Category 3 and higher UTP cable
